Запчасти для экскаваторов Kobelco и New Holland

Make Model Serial Years Engine Hydraulic Pump Valve Block Slew Drive Assembly Slew Motor Slew Reduction Slew Ring Final Driv

Kobelco K Series Excavators
Kobelco K903A K2748 1/76-12/03 Isuzu 4JB1 2441U141F1     2441U246F1 24100J2253F1 2425U139 24100N1166F1
Kobelco K903B LE3401 1/85-12/03 Isuzu 4JB1 2441U369F1   24100J4291F1 2441U312F2 24100J4290F1 2425U232F1 24100J3247F4
Kobelco K903C LE5701 1/87-12/03 Isuzu 4JB1 2437U185F1   24100J6266F1 2441U533F1 24100J6267F1 2425U235F1 24100J3247F4
Kobelco K903-II LE6601 1/88-12/03 Isuzu 4JB1 2437U185F1   24100J6266F1 2441U533F1 24100J6267F1 2425U235F2 2441U532F1
Kobelco K903-II LE7872 1/88-12/03 Isuzu 4JB1 2437U201F1 2436U1317F1 24100J10812F1 2441U789F1   2425U235F2 2441U532F1
Kobelco K904D LW5801 1/84-12/03 Isuzu 4BD1 2441U410F1   24100J4603F1 2441U250F1 24100J4606F1 2425U161F1 24100J2112F5
Kobelco K904DL LX1201 1/84-12/03 Isuzu 4BD1 2441U410F1   24100J4603F2 2441U250F1 24100J4606F2 2425U161F1 24100J2112F5
Kobelco K904E LW7801 1/86-12/03 Isuzu 4BD1 2437U177F1   24100J6254F2 2441U555F2 24100J6221F1 2425U236F1 2441U524F1
Kobelco K904EL LX1401 1/86-12/03 Isuzu 4BD1 2437U177F1   24100J6254F2 2441U555F2 24100J6221F1 2425U236F1 2441U524F1
Kobelco K904L-II LX1501 1/88-12/03 Isuzu 4BD1 2437U191F1 2436U1329F2 24100J9087F6 2441U754F2 24100J9088F6 2425U238F1 2441U753F1
Kobelco K904L-II LX1537 1/88-12/03 Isuzu 4BD1 2437U191F2 2436U1329F2 24100J9087F7 2441U754F3 24100J9088F6 2425B238F1 2441U753F1
Kobelco K904-II YW0101 1/88-12/03 Isuzu 4BD1 2437U191F1 2436U1329F2 24100J9087F6 2441U754F2 24100J9088F6 2425U238F1 2441U753F1
Kobelco K904-II YW1119 1/88-12/03 Isuzu 4BD1 2437U191F2 2436U1329F2 24100J9087F7 2441U754F2 24100J9088F6 2425B238F1 2441U753F1
Kobelco K905 LP0004 1/82-12/03 Isuzu 4BD1 2441U347F2   24100J3863F1 2441U348F1 24100J3879F1 2425U150F1 24100J2112F6
Kobelco K905 LP0601 1/82-12/03 Isuzu 4BD1 2441U347F3   24100N3450F2 2441U348F1 24100J6728F2 2425U161FT 24100J2112F6
Kobelco K905A LP1601 1/83-12/03 Isuzu 4BD1-T 2437U175F1   24100J6254F1 2441U555F1 24100J6221F1 2425U236F1 2441U524F1
Kobelco K905-II LP2401 1/00-12/03 Isuzu 4BD1-T 2437U188F1 2436U1265F1 24100J6469F2 2441U748F2 24100J9434F1 24100N4036F2 2441U750F1
Kobelco K907C LN4201 1/84-12/03 Mitsubishi 6D14 2441U436F1   24100J4605F1 2441U349F2 24100J4604F1 2425U159F1 24100X1319F1
Kobelco K907D LN7001 1/86-12/03 Mitsubishi 6D14-T 2437U172F1   24100J6173F1 2441U547F1 24100J6175F1 24100N3631F1 24100X1996F1
Kobelco K907-II LN2956 1/88-12/03 Mitsubishi 6D14-T 2437U205F1   24100J10739F2 2441U790F1 24100J9301F5 24100N3981F2 24100X1366F2
Kobelco K909A LQ0795 1/83-12/03 Mitsubishi 6D22 2441U474F1 2436U1031F1   2441U476F1
Kobelco K909LC-II LL1207 1/87-12/03 Mitsubishi 6D15-T 2437U192F1 2436U1313F1 24100J6349F3 2441U756F1   24100N4118F1 24100X1367F2
Kobelco K909LC-II LL1488 1/87-12/03 Mitsubishi 6D15-T 2437U206F1 2436U1231F1 24100J10740F2 2441U791F1   24100N4118F1 24100X1367F2
Kobelco K912A LC2003 1/85-12/03 Mitsubishi 6D22 2441U681F1   24100J6740F2 2441U683F1 24100J6739F2 24100N3854F1 2441U454F2
Kobelco K912-II LC2301 11/88-12/03 Mitsubishi 6D22-T 2437U194F1   24100J10325F2 2441U760F1   2425U240F1 2441U787F1
Kobelco K914 LR0143 1/79-12/03 Mitsubishi 8DC9 2441U353F1   24100X533F2 2441U190F3   2425U128 2441U341F1
Kobelco K916 LS0007 1/86-12/03 Mitsubishi 6D22 2441U684F1   24100J4648F4 2441U705F1 24100J4649F2 24100N3815F1 24100N3638F2
Kobelco K916-II LS0201 1/03-12/04 Mitsubishi 6D22-T 2441U774F1 2436U1345F1 24100J10432F1 2441U775F1 24100J10363F2 24100N5635F1 24100N5661F1
Kobelco K935 LU0067 1/76-12/03 Mitsubishi 6D22 2441U210F1     B41N0002F3 24100X397F2 2425U126 2441U209F1
24100X419F3
Kobelco K935 LU0096 1/76-12/03 Mitsubishi 6D22 2441U361F1     B41N0002F3 24100X397F2 2425U126 2441U359F1
24100X419F4
Kobelco Mark-II Excavators
Kobelco SK60-II LE11001 1/91-12/03 Isuzu 4JB1 2437U390F1 2436U1429F1 24100J11943F1 2441U814F1   2425U252F1 2441U815F1
Kobelco SK400-II LS0201 1/93-12/01 Mitsubishi 6D22-T 2441U774F1 2436U1345F1 24100J10432F2 2441U775F1 24100J10363F2   24100N5661F1
Kobelco SK400LC-II YS0201 1/91-12/95 Mitsubishi 6D22-T 2441U774F1 2436U1345F1 24100J10432F2 2441U775F1 24100J10363F2   24100N5661F1
Kobelco Mark-III Excavators
Kobelco SK60-III LE14101 1/91-1/96 Isuzu 4JB1 2437U390F1 2436U1429F1 24100J11943F1 2441U814F1   2425U252F1 2441U815F1
Kobelco SK100-III LE11001 1/90-12/95 Isuzu 4BD1 2437U405F1 2436U2633F1 24100J11586F5 2441U825F1 24100J9088F9 2425U251F1 2441U829F1
Kobelco SK100L-III LX10101 1/94-12/95 Isuzu 4BD1 YW10V00002F1 YW30V00001F1 YW32W00001F1 YW15V00001F1 YW32W00004F1 LP40F00001F1 LP15V00001F1
Kobelco SK120-III LP01601 1/91-12/95 Isuzu 4BD1-T 2437U400F1 2436U2635F1 24100J11722F1 2441U828F1 24100J11681F1 2425U251F1 2441U829F1
Kobelco SK120LC-III YPU0301 1/95-12/95 Isuzu 4BD1-T 2437U400F1 2436U2631F1 24100J11722F1 2441U828F1 24100J11681F1 2425U251F1 2441U829F1
Kobelco SK120-III LP08001 1/91-12/95 Isuzu 4BD1-T 2437U400F1 2436U2635F1 24100J11722F4 2441U963F1 24100J11681F3 24100N7529F1 2441U829F1
Kobelco SK120LC-III YP01801 1/95-12/95 Isuzu 4BD1-T 2437U400F1 2436U2635F1 24100J11722F4 2441U963F1 24100J11681F3 24100N7529F1 2441U829F1
Kobelco SK150LC-III YM000101 1/93-12/95 Isuzu 4BD1-T 2437U489F1 2436U2869F1 24100J16122F2 2441U804F1   24100N8102F1 2441U995F1
Kobelco SK200-III YN07922 1/91-12/99 Mitsubishi 6D31-T 2437U389F1 2436U1231F11 24100J11091F2 2441U819F1   24100N6347F1 24100J11090F5
Kobelco SK200LC-III YQ01226 1/91-12/91 Mitsubishi 6D31-T 2437U389F1 2436U1231F11 24100J11091F2 2441U819F1   24100N6347F1 24100J11090F5
Kobelco SK220-III LQ02701 1/91-12/95 Mitsubishi 6D31-T 2437U402F1 2436U2624F5 24100J11720F4 2441U927F1   24100N7441F1 24100J11675F4
Kobelco SK220LC-III LL02001 1/91-12/97 Mitsubishi 6D31-T 2437U402F1 2436U2624F5 24100J11720F4 2441U927F1   24100N7441F1 24100J11675F4
Kobelco SK300-III LCU0001 1/93-12/99 Mitsubishi 6D22-T 2437U472F1 2436U2669F1 24100J13528F3 2441U947F1   2425U262F1 2441U787F2
Kobelco SK300LC-III YCU0001 1/93-12/93 Mitsubishi 6D22-T 2437U472F1 2436U2669F1 24100J13528F3 2441U947F1   2425U262F1 2441U787F2
Kobelco SK300-2-III LC03201 1/93-12/03 Mitsubishi 6D22-T 2437U474F1 2436U2668F1 24100J13528F3 2441U947F1   2425U262F1 2441U948F1
Kobelco SK300LC-2-III YC00901 1/93-12/93 Mitsubishi 6D22-T 2437U474F1 2436U2668F1 24100J13528F3 2441U947F1   2425U262F1 2441U948F1
Kobelco SK310-2-III LC03801   Mitsubishi 6D22-T 2437U502F3 2436U2885F1 24100J13528F4 2441U947F2   2425U262F1 2441U787F31
Kobelco SK310LC-2-III YC001101   Mitsubishi 6D22-T 2437U502F3 2436U2885F1 24100J13528F4 2441U947F2   2425U262F1 2441U787F31
Kobelco SK400-III LSU0001 1/93-12/01 Mitsubishi 6D22-T 2437U473F1 2436U2671F1 24100J13553F3 2441U949F1 24100J13532F3 2425U340F1 24100N5661F1
Kobelco SK400LC-III YSU0001 1/93-12/96 Mitsubishi 6D22-T 2437U473F1 2436U2671F1 24100J13553F3 2441U949F1 24100J13532F3 2425U340F1 24100N5661F1
Kobelco Mark-IV Excavators
Kobelco SK60-IV LE17596 1/95-12/03 Isuzu 4JB1 2437U390F1 2436U1429F1 24100J11943F1 2441U814F1   2425U252F1 2441U815F1
Kobelco SK100-IV YWU1001 1/95-12/03 Cummins 4BT 3.9 24100N8520F2 2436U2906F1 2441U827F2 2441U825F1 2436U1283F1 24100N7529F1 LP15V00001F1
Kobelco SK115DZ-IV LPU5001 1/98-12/99 Cummins 4BT 3.9 2437U509F1 2436U2908F1 24100J11722F5 2441U963F1 24100J11681F3 24100N7529F1 LP15V00001F1
Kobelco SK120-IV LPU1001 1/95-12/95 Cummins 4BT 3.9 2437U509F1 2436U2908F1 24100J11722F5 2441U963F2 24100J11681F3 24100N7529F1 LP15V00001F1
Kobelco SK120LC-IV YPU1001 1/94-12/95 Cummins 4BT 3.9 2437U509F1 2436U2908F1 24100J11722F5 2441U963F2 24100J11681F3 24100N7529F1 LP15V00001F1
Kobelco SK130LC-IV LPU0201 1/98-12/98 Cummins 4BT 3.9 2437U509F2 2436U2908F1 24100J11722F5 2441U963F2 24100J11681F3 LP40FU0001F1 LP15V00001F1
Kobelco SK130LC-IV YPU2001 1/98-12/98 Cummins 4BT 3.9 2437U509F2 2436U2908F1 24100J11722F5 2441U963F2 24100J11681F3 LP40FU0001F1 LP15V00001F1
Kobelco SK150LC-IV YMU01001 1/95-12/99 Cummins 4BT 3.9 2437U489F2 2436U2905F1 24100J16122F2 2441U819F3 24100J16328F1 24100N8102F1 2441U995F1
Kobelco SK150LC-IV YMU01501 1/95-12/99 Cummins 4BT 3.9 2437U489F2 2436U2905F1 24100J16122F2 2441U819F3 24100J16328F1 24100N8102F1 2441U995F2
Kobelco SK160LC-IV YMU2U10101 1/02-12/06 Cummins 4BT 3.9 2437U489F2 2436U2905F1 24100J16122F2 2441U819F3 24100J16328F1 24100N8102F1 2441U995F2
Kobelco SK200-IV YNU0201 1/97-12/97 Cummins 6BTA 5.9-C 2437U389F3 2436U2817F3 24100J11091F9 2441U819F3 24100J13639F4 YN40FU0001F1 YN15V00003F1
Kobelco SK200LC-IV YQU2001 1/95-12/95 Cummins 6BTA 5.9-C 2437U389F3 2436U2817F3 24100J11091F9 2441U819F3 24100J13639F4 YN40FU0001F1 YN15V00003F1
Kobelco SK200-IV YNU0501 1/95-12/97 Cummins 6BTA 5.9-C 2437U389F3 2436U2817F3 24100J11091F9 2441U819F3 24100J13639F4 YN40FU0001F1 YN15V00007F1
Kobelco SK200LC-IV YQU3101 1/95-12/95 Cummins 6BTA 5.9-C 2437U389F3 2436U2817F3 24100J11091F9 2441U819F3 24100J13639F4 YN40FU0001F1 YN15V00007F1
Kobelco SK210-IV YNJ-00501 1/98- Mitsubishi 6D34-TE1 2437U389F3 2436U2817F3 24100J11091F9 2441U819F3 24100J13639F3 24100N7440F1 YN15V00007F1
Kobelco SK210LC-IV YQJ-00101 1/98- Mitsubishi 6D34-TE1 2437U389F3 2436U2817F3 24100J11091F9 2441U819F3 24100J13639F3 24100N7440F1 YN15V00007F1
Kobelco SK210-IV YNU0501 1/04-12/04 Cummins 6BTA 5.9-C 2437U389F3 2436U2817F3 24100J11091F11 2441U819F3 24100J13639F4 YN40FU0001F1 YN15V00007F1
Kobelco SK210LC-IV YQU3101 1/00-12/02 Cummins 6BTA 5.9-C 2437U389F3 2436U2817F3 24100J11091F11 2441U819F3 24100J13639F4 YN40FU0001F1 YN15V00007F1
Kobelco SK220-IV LQU0101 1/95-12/00 Cummins 6BTA 5.9-C 2437U402F3 2436U2816F2 24100J11720F5 2441U927F1 24100J13483F3 LQ40FU0001F1 LQ15V00003F1
Kobelco SK220LC-IV LLU1201 1/95-12/97 Cummins 6BTA 5.9-C 2437U402F3 2436U2816F2 24100J11720F2 2441U927F1 24100J13483F2 24100N7441F1 24100J11675F2
Kobelco SK220-IV LQ02101 1/95-12/00 Cummins 6BTA 5.9-C 2437U402F1 2436U2521F1 24100J11720F2 2441U927F1 24100J13483F1 24100N6384F1 24100J11675F2
Kobelco SK220LC-IV LLU1801 1/95-12/97 Cummins 6BTA 5.9-C 2437U402F4 2436U2816F2 24100J11720F4 2441U927F1 24100J13483F2 24100N6384F1 24100J11675F4
Kobelco SK250-IV LQU0101 1/95-8/07 Cummins 6BTA 5.9-C 2437U402F3 2436U2816F2 24100J11720F5 2441U927F1 24100J13483F3 LQ40FU0001F1 LQ15V00003F1
Kobelco SK250LC-IV LLU1201 1/95-12/95 Cummins 6BTA 5.9-C 2437U402F3 2436U2816F2 24100J11720F4 2441U927F1 24100J13483F2 24100N7441F1 24100J11675F4
Kobelco SK250LC-IV LLU1801 1/95-5/07 Cummins 6BTA 5.9-C 2437U402F3 2436U2816F2 24100J11720F5 2441U927F1 24100J13483F3 LQ40FU0001F1 LQ15V00003F1
Kobelco SK250NLC-IV LLU5059 1/95-12/06 Cummins 6BTA 5.9-C 2437U402F3 2436U2816F2 24100J11720F5 2441U927F1 24100J13483F3 LQ40FU0001F1 LQ15V00003F1
Kobelco SK270LC-IV LBU0001 1/96-12/00 Cummins 6BTA 5.9-C 2437U402F3 2436U2816F2 24100J11720F4 2441U927F1 24100J13483F2 LC40FU0001F1 2441U787F3
Kobelco SK300-IV LCU0001 1/95-12/99 Cummins 6BTA 5.9-C 2437U472F2 2436U2913F1 24100J13528F4 2441U947F2   LC40FU0001F1 2441U787F3
Kobelco SK300LC-IV YCU0301 1/95-12/06 Mitsubishi 6D22-T 2437U472F2 2436U2913F1 24100J13528F4 2441U947F2   LC40FU0001F1 2441U787F3
Kobelco SK300LC-IV YCU0501 1/95-12/06 Cummins 6BTA 5.9-C 2437U472F2 2436U2913F1 24100J13528F4 2441U947F2   LC40FU0001F1 2441U787F3
Kobelco SK330-IV LCU0101 1/98-12/04 Cummins 6BTA 5.9-C 2437U472F2 2436U2913F1 24100J13528F5 2441U947F3   LC40FU0001F1 2441U1029F1
Kobelco SK330LC-IV YCU0611 1/02-12/05 Cummins 6BTA 5.9-C 2437U472F2 2436U2913F1 24100J13528F5 2441U947F3   LC40FU0001F1 2441U1029F1
Kobelco SK400-IV LSU0001 1/95-12/03 Cummins MTA11-C320 2437U511F1 2436U2914F1 24100J13553F4 2441U949F2 24100J13532F3 LS40FU0001F1 24100N5661F3
Kobelco SK400LC-IV YSJ00002 1/95-12/95 Mitsubishi 6D22-T 2437U473F1 2436U2914F1 24100J13553F4 2441U949F2 24100J13532F3 2425U340F1 24100N5661F2
Kobelco SK400LC-IV YSU0200 1/95-12/95 Cummins MTA11-C320 2437U511F1 2436U2914F1 24100J13553F4 2441U949F2 24100J13532F3 LS40FU0001F1 24100N5661F3
Kobelco SK460-IV LS000839 1/95-12/95 Mitsubishi 6D24-TCE1 2437U529F1 2436U2886F1   2441U802F1 24100J13532F3 2425U340F1 24100N5661F3
Kobelco SK460LC-IV YS000739 1/95-12/95 Mitsubishi 6D24-TCE1 2437U529F1 2436U2886F1   2441U802F1 24100J13532F3 2425U340F1 24100N5661F3
Kobelco Mark-V Excavators
Kobelco SK60-V LE17701 12/95-12/03 Isuzu 4JB1 LE10V00001F1 LE30V00001F1 YR15V00004F1 YR15V00003F1 YR32W00002F1 LE40F00001F1 LE15V00002F1
Kobelco SK100-V YW07901   Isuzu 4BG1 YW30P00004F1 YW30P00006F1 YW32W00001F1 YW15V00001F1   LP40F00001F1 2441U994F2
Kobelco SK100L-V LX010201   Isuzu 4BG1 YW30P00004F1 YW30P00006F1 YW32W00001F1 YW15V00001F1   LP40F00001F1 2441U994F2
Kobelco SK120-V LP11001 9/02-12/03 Isuzu 4BD1-T LP10V00001F1 LP30V00001F2 LP32W00001F1 YW32W00004F1   LP40F00001F1 LP15V00001F1
Kobelco SK120LC-V YP02301 1/94-12/95 Isuzu 4BD1-T LP10V00001F1 LP30V00001F2 LP32W00001F1 YW32W00004F1   LP40F00001F1 LP15V00001F1
Kobelco SK120-V LP13601 9/02-12/03 Isuzu 4BG1-T LP10V00003F1 LP30V00004F1 LP32W00001F1 YW32W00004F1   LP40F00001F1 YW15V00005F1
Kobelco SK120LC-V YP02501 1/94-12/95 Isuzu 4BG1-T LP10V00003F1 LP30V00004F1 LP32W00001F1 YW32W00004F1   LP40F00001F1 YW15V00005F1
Kobelco SK200-V YNT00001 1/99-12/03 Mitsubishi 6D34-T YN10V00004F1 YN30V00021F2 YN32W00002F2 YN15V00002F2   YN40F00002F1 YN15V00007F1
Kobelco SK200LC-V YQT00001 1/95-12/95 Mitsubishi 6D34-T YN10V00004F1 YN30V00021F2 YN32W00002F2 YN15V00002F2   YN40F00002F1 YN15V00007F1
Kobelco SK200-V YN018001 1/98-12/03 Mitsubishi 6D34-T YN10V00001F1 YN30V00001F1 YN32W00002F1 YN15V00002F1   YN40F00001F1 YN15V00003F1
Kobelco SK200LC-V YQ002301 1/95-12/95 Mitsubishi 6D34-T YN10V00001F1 YN30V00001F1 YN32W00002F1 YN15V00002F1   YN40F00001F1 YN15V00003F1
Kobelco SK200-V YN023301 1/98-12/03 Mitsubishi 6D34-T YN10V00004F1 YN30V00021F1 YN32W00002F2 YN15V00002F2   YN40F00002F1 YN15V00003F2
Kobelco SK200LC-V YQ002801 1/95-12/95 Mitsubishi 6D34-T YN10V00004F1 YN30V00021F1 YN32W00002F2 YN15V00002F2   YN40F00002F1 YN15V00003F2
Kobelco SK220-V LQT00001 1/95 Mitsubishi 6D15-T LQ10V00003F2 LQ30V00002F2 LQ32W00001F3 LQ15V00001F3   LQ40F00002F1 LQ15V00003F1
Kobelco SK220LC-V LLT00001 1/95 Mitsubishi 6D15-T LQ10V00003F2 LQ30V00002F2 LQ32W00001F3 LQ15V00001F3   LQ40F00002F1 LQ15V00003F1
Kobelco -6 Excavators
Kobelco SK130LC YPU1001 1/98-12/98   2437U509F2 2436U2908F1   2441U962F2 24100J11681F3 24100N7529F1 LP15V00001F1
Kobelco SK160LC YM02U0101 11/00-12/02   YM10V00001F1 YM30V00001F2   YN15V00002F4 YM32W00001F1 YM40F00002F1 YM15V00001F1
Kobelco SK160LC-6E YM03U0523 8/04-12/07 Mitsubishi 4D34-TL YM10V00002F2 YM30V00006F1 YM15V00003F1 YM15V00025F1 YM32W00002F1 YM40F00002F1 YM15V00001F2
Kobelco SK170LC-6E YM03-00501 8/04-12/07 Mitsubishi 4D34-TL YM10V00001F3 YM30V00007F1 YM15V00003F1 YM15V00025F1 YM32W00001F1 YM40F00002F1 YM15V00001F2
Kobelco SK170LC-6ES YM05-00651 8/04-12/07 Mitsubishi 4D34-TL YM10V00001F4 YM30V00007F1 YM15V00003F2 YM15V00025F4 YM32W00001F1 YM40F00002F1 YM15V00001F2
Kobelco SK200 YNT0003 1/97-12/06   YN10V00004F1 YN30V00021F1   YN15V00002F4 YN32W00004F1 24100N7440F1 YN15V00003F2
Kobelco SK200-6 YN10-30001 1/01-12/03 Mitsubishi 6D34-TLU2D YN10V00007F1     YN15V00002F4 YN32W00004F1 YN40F00007F1 YN15V00011F1
Kobelco SK200LC-6 YQ10-03501 1/95-12/06 Mitsubishi 6D34-TLU2D YN10V00007F1     YN15V00002F2 YN32W00002F2 YN40F00007F1 YN15V00011F1
Kobelco SK200-6ES YN10-38001 1/03-12/04 Mitsubishi 6D34-TLU2D YN10V00023F1     YN15V00026F5 YN32W00004F1 YN40F00019F2 YN15V00017F2
Kobelco SK200LC-6ES YQ10-05501 1/95-12/06 Mitsubishi 6D34-TLU2D YN10V00023F1     YN15V00026F5 YN32W00004F1 YN40F00019F2 YN15V00017F2
Kobelco SK210-6 YN07-30001 2/00-12/12 Mitsubishi 6D34-TUA YN10V00007F1 YN30V00033F1 YN15V00010F1 YN15V00002F4 YN32W00004F1 YN40F00012F1 YN15V00011F1
Kobelco SK210LC-6 YQ07-03501 2/00-12/12 Mitsubishi 6D34-TUA YN10V00007F1 YN30V00033F1 YN15V00010F1 YN15V00002F4 YN32W00004F1 YN40F00012F1 YN15V00011F1
Kobelco SK210LC YQ07U0101 1/01-12/02 Mitsubishi 6D34-TUA YN10V00013F1 YN30V00033F2 YN15V00010F1 YN15V00002F4 YN32W00004F1 YN40F00012F1 YN15V00011F1
Kobelco SK210-6E YN08-33001 1/02-12/12 Mitsubishi 6D34-TLE2A YN10V00029F1 YN30V00089F2 YN15V00026F1 YN15V00025F1 YN32W00004F1 YN40F00019F1 YN15V00011F4
Kobelco SK210LC-6E YQ08-04501 1/02-12/12 Mitsubishi 6D34-TLE2A YN10V00029F1 YN30V00089F2 YN15V00026F1 YN15V00025F1 YN32W00004F1 YN40F00019F1 YN15V00011F4
Kobelco SK210-6E YN09-35146 1/04- Mitsubishi 6D34-TLE2A YN10V00029F2 YN30V00089F2 YN15V00026F5 YN15V00025F4 YN32W00004F1 YN40F00019F2 YN15V00011F4
Kobelco SK210LC-6E YQ09-04933 1/04- Mitsubishi 6D34-TLE2A YN10V00029F2 YN30V00089F2 YN15V00026F5 YN15V00025F4 YN32W00004F1 YN40F00019F2 YN15V00011F4
Kobelco SK210-6ES YN10-38001 1/05- Mitsubishi 6D34-TLU2D YN10V00029F2 YN30V00089F2 YN15V00026F5 YN15V00025F4 YN32W00004F1 YN40F00019F2 YN15V00011F4
Kobelco SK210LC-6ES YQ10-05501 1/05- Mitsubishi 6D34-TLU2D YN10V00029F2 YN30V00089F2 YN15V00026F5 YN15V00025F4 YN32W00004F1 YN40F00019F2 YN15V00011F4
Kobelco SK250-6 LQ08-04501 1/02- Mitsubishi 6D34-TLE1 LQ10V00005F1 LQ30V00010F1 LQ15V00006F1 LQ15V00008F1 LQ32W00007F1 24100N7441F1 LQ15V00007F1
Kobelco SK250LC-6 LL08-03001 1/02- Mitsubishi 6D34-TLE1 LQ10V00005F1 LQ30V00010F1 LQ15V00006F1 LQ15V00008F1 LQ32W00007F1 24100N7441F1 LQ15V00007F1
Kobelco SK250-6E LQ09-04801 1/03-12/07 Mitsubishi 6D34-TLE2A LQ10V00011F1 LQ30V00018F1 LQ15V00014F1 LQ15V00015F1 LQ32W00009F1 LQ40F00004F1 LQ15V00007F2
Kobelco SK250LC-6E LL09-03501 1/03-12/07 Mitsubishi 6D34-TLE2A LQ10V00011F1 LQ30V00018F1 LQ15V00014F1 LQ15V00015F1 LQ32W00009F1 LQ40F00004F1 LQ15V00007F2
Kobelco SK250LC-6E LL09U0575 1/03-12/07 Mitsubishi 6D34-TLE2A LQ10V00006F1 LQ30V00019F1 LQ15V00014F1 LQ15V00015F1 LQ32W00009F1 LQ40F00004F1 LQ15V00007F2
Kobelco SK250-6E LQ10-04915 1/04- Mitsubishi 6D34-TLE2A LQ10V00011F2 LQ30V00018F1 LQ15V00014F2 LQ15V00015F2 LQ32W00009F1 LQ40F00004F1 LQ15V00019F1
Kobelco SK250LC-6E LL10-03666 1/04- Mitsubishi 6D34-TLE2A LQ10V00011F2 LQ30V00018F1 LQ15V00014F2 LQ15V00015F2 LQ32W00009F1 LQ40F00004F1 LQ15V00019F1
Kobelco SK250-6ES LQ11-05201 5/05-8/07 Mitsubishi 6D34-TLE2B LQ10V00011F2 LQ30V00018F1 LQ15V00014F2 LQ15V00015F2 LQ32W00009F1 LQ40F00004F1 LQ15V00019F1
Kobelco SK250LC-6ES LL11-04001 11/04-5/07 Mitsubishi 6D34-TLE2B LQ10V00011F2 LQ30V00018F1 LQ15V00014F2 LQ15V00015F2 LQ32W00009F1 LQ40F00004F1 LQ15V00019F1
Kobelco SK330 LC06-05501 1/02-12/02 Mitsubishi 6D16-TLE1 LC10V00001F1 LC30V00001F1 LC32W00001F1 LC15V00003F1 24100J16661F4 LC40F00009F1 LC15V00005F1
Kobelco SK330LC YC06-02501 1/02-12/02 Mitsubishi 6D16-TLE1 LC10V00001F1 LC30V00002F1 LC32W00001F1 LC15V00003F1 24100J16661F4 LC40F00009F1 LC15V00005F1
Kobelco SK330-6E LC08-06201 1/03-12/06 Mitsubishi 6D16-TLE2A LC10V00004F3 LC30V00001F3 LC32W00001F1 LC15V00003F1 24100J16661F4 LC40F00009F1 LC15V00005F2
Kobelco SK330LC-6E YC08-03001 1/03-12/06 Mitsubishi 6D16-TLE2A LC10V00005F3 LC30V00007F2 LC32W00001F1 LC15V00006F1 24100J16661F4 LC40F00009F1 LC15V00005F2
Kobelco SK330-6E LC09-06323 1/03-12/06 Mitsubishi 6D16-TLE2D LC10V00004F4 LC30V00001F3 LC32W00001F1 LC15V00003F2 24100J16661F4 LC40F000012F1 LC15V00005F4
Kobelco SK330LC-6E YC09-03088 1/03-12/06 Mitsubishi 6D16-TLE2D LC10V00005F4 LC30V00007F2 LC32W00001F1 LC15V00006F3 24100J16661F4 LC40F00012F1 LC15V00005F4
Kobelco SK480 LS06-01001 1/00-12/08 Mitsubishi 6D24-TLU2C LS10V00001F1 LS30V00002F2 LS32W00001F1 LS15V00002F1 24100J13532F5 LS40F00003F1 LS15V00003F1
Kobelco SK480LC YS06-00901 1/00-12/08 Mitsubishi 6D24-TLU2C LS10V00001F1 LS30V00002F2 LS32W00001F1 LS15V00002F1 24100J13532F5 LS40F00003F1 LS15V00003F1
Kobelco SK480 LS07-01201 1/00-12/08 Mitsubishi 6D24-TLU2G LS10V00001F3 LS30V00002F3 LS32W00001F1 LS15V00002F1 24100J13532F5 LS40F00003F1 LS15V00003F1
Kobelco SK480LC YS07-01101 1/00-12/08 Mitsubishi 6D24-TLU2G LS10V00001F3 LS30V00002F3 LS32W00001F1 LS15V00002F1 24100J13532F5 LS40F00003F1 LS15V00003F1
Kobelco SK480 LS08-01236 1/00-12/08 Mitsubishi 6D24-TLU2G LS10V00001F4 LS30V00002F3 LS32W00001F1 LS15V00002F2 24100J13532F6 LS40F00013F1 LS15V00003F2
Kobelco SK480LC YS08-01146 1/00-12/08 Mitsubishi 6D24-TLU2G LS10V00001F4 LS30V00002F3 LS32W00001F1 LS15V00002F2 24100J13532F6 LS40F00013F1 LS15V00003F2
Kobelco SK480-6S LS09-01506 1/00-12/08 Mitsubishi 6D24-TLU2G LS10V00001F4 LS30V00002F3 LS32W00001F1 LS15V00002F2 24100J13532F6 LS40F00013F1 LS15V00003F2
Kobelco SK480LC-6S YS09-01301 1/00-12/08 Mitsubishi 6D24-TLU2G LS10V00001F4 LS30V00002F3 LS32W00001F1 LS15V00002F2 24100J13532F6 LS40F00013F1 LS15V00003F2
Kobelco -8 Excavators
Kobelco SK170-8 YM04U1601 5/07-12/12 FPT F4GE9484D*J6 YM10V00006F2 YM30V00011F1 YM15V00004F1 YM15V00006F1 YM32W00004F1 YM40F00006F1 YM15V00007F1
Kobelco SK170-8 YM07U1901 4/11-12/12 FPT F4GE9484D*J6 YM10V00005F2 YM30V00011F1 YM15V00004F3 YM15V00006F1 YM32W00008F2 YM40F00006F1 YM15V00007F1
Kobelco SK200-8 YN11-45001 1/06-12/09 Hino J05E-TG YN10V00036F1 YN30V00101F1 YN15V00036F1 YN15V00035F1 YN32W00019F1 YN40F00026F1 YN15V00037F1
Kobelco SK210-8 YN11-45001 1/07-12/12 Hino J05E-TG YN10V00036F1 YN30V00101F2 YN15V00036F1 YN15V00035F1 YN32W00019F1 YN40F00033F2 YN15V00037F1
Kobelco SK210LC-8 YQ11-06001 1/02-12/07 Hino J05E-TG YN10V00036F1 YN30V00101F2 YN15V00036F1 YN15V00035F1 YN32W00019F1 YN40F00033F2 YN15V00037F1
Kobelco SK210-8 YN11-48373 1/07-12/12 Hino J05E-TG YN10V00036F1 YN30V00101F2 YN15V00036F1 YN15V00035F1 YN32W00022F1 YN40F00033F2 YN15V00037F1
Kobelco SK210LC-8 YQ11-06315 1/02-12/07 Hino J05E-TG YN10V00036F1 YN30V00101F2 YN15V00036F1 YN15V00035F1 YN32W00022F1 YN40F00033F2 YN15V00037F1
Kobelco -9 Excavators
Kobelco SK170-9   1/12-12/13 FPT F4HFE9484D*J619 YB10V00006F2 YM30V00013F1 YM15V00008F1 YM15V00006F1 YM32W00009F1 YM40F00006F1 YN15V00051F3
Kobelco SK170-9 YM08U2000 1/12-12/13 FPT F4HFE413H*A002 YB10V00006F2 YM30V00013F1 YM15V00008F1 YM15V00006F1 YM32W00009F1 YM40F00006F1 YN15V00051F4
Kobelco SK210LC-9 YQ13-10158   Hino J05ETJ-KSDM YN10V00040F4 YN30V00129F2 YN15V00054F1 YN15V00055F1 YN32W00025F1 YN40F00026F1 YN15V00051F5
Kobelco SK210-9   1/12-12/13 FPT F4GE9684E*J611 YN10V00036F4 YN30V00126F1 YN15V00054F1 YN15V00055F1 YN32W00025F1 YN40F00026F1 YN15V00037F2
Kobelco SK210-9 LQ13U5200 10/12-12/13 FPT F4HFE613S*A003 YN10V00043F1 YN30V00126F1 YN15V00054F1 YN15V00055F1 YN32W00025F1 YN40F00026F2 YN15V00037F2
Kobelco SK260-9 LL14U1700 3/11-12/13 FPT F4HFE613R*A003 LQ10V00018F2 LQ30V00034F1 LQ15V00025F1 LQ15V00023F1 LQ32W00014F2 LQ40F00015F1 LQ15V00031F1
Kobelco SK295-9 LB07U0900 2/11-12/13 FPT F4HFE613P*A003 LQ10V00018F4 LB30V00014F1 LB15V00017F1 LC15V00022F1 LB32W00010F1 LB40F00010F1 LB15V00014F1
Kobelco SK350LC-9 YC12-10001   Hino J08E-UV-KSDF LC10V00029F4
LC10V00030F4		 LC30V00039F1 LC15V00027F2 LC15V00022F2 LC32W00011F1 LC40F00018F1 LC15V00023F2
Kobelco SK350-9 YC12U2401 9/11-12/13 Hino J08E-UV LC10V00029F3
LC10V00030F3		 LC30V00039F1 LC15V00027F2 LC15V00022F2 LC32W00011F1 LC40F00018F1 LC15V00023F2
Kobelco SK350-9 YC13U3001 9/12-12/13 Hino J08E LC10V00029F4
LC10V00030F4		 LC30V00039F2 LC15V00027F2 LC15V00022F2 LC32W00011F1 LC40F00018F1 LC15V00023F2
Kobelco SK485-9 YS12U0802 11/11-12/13 Hino P11C LS10V00021F3 LS30V00017F1   LS15V00026F1
LS15V00027F1		 LS32W00016F1
LS32W00016F1		 LS40F00010F1 LS15V00020F3
Kobelco SK850-9 LY01-00101 12/07-12/13 Komatsu SAA6D140E-5 LV10V00007F1 LV30V00009F1 LV15V00004F1
LV15V00005F1		 LV15V00002F2
LV15V00002F2		 LV32W00002F1
LV32W00003F1		 LV40F00003F1 LV53D00007F2
Kobelco -10 Excavators
Kobelco SK180-10 YM09-01001   Hino J05EUM-KSST YM10V00008F1 YM30V00018F1 YM15V00008F1 YM15V00006F1 YM32W00009F1 YM40F00010F1 YN15V00051F7
Kobelco SK180LC-10E YM09005001 11/19- Hino J05EUM-KSST YM10V00008F1 YM30V00018F1 YM15V00008F1 YM15V00006F1 YM32W00009F1 YM40F00010F1 YN15V00051F7
Kobelco SK210-10 YN15-80001 2/16- Hino J05EUM-KSSC YN10V00075F1
YN10V00079F1		 YN30V00151F1 YN15V00078F1 YN15V00077F1 YN32W00025F1 YN40F00042F2 YN15V00051F6
Kobelco SK210LC-10 LQ15-20001 2/16- Hino J05EUM-KSSC YN10V00075F1
YN10V00079F1		 YN30V00151F1 YN15V00078F1 YN15V00077F1 YN32W00025F1 YN40F00042F1 YN15V00051F5
Kobelco SK210HLC-10 WB03-00501 5/18- Hino J05EUM-KSSN YQ10V00037F1 YN30V00162F1 WB15V00001F2 YN76S00042F1 WB32W00005F2 YN40F00042F1 YN15V00051F7
Kobelco SK210HLC-10E   12/19- Hino J05EVA-KSDM
Kobelco SK240SN-10E   11/19- Hino J05EUM-KSSS
Kobelco SK260-10 LQ16-10001 02/19- Hino J05EUN-KSSD LQ10V00037F1
LQ10V00040F1		 LQ30V00051F1 LQ15V00038F2 LQ15V00037F1 LQ32W00021F2 LQ40F00021F1 LQ15V00031F3
Kobelco SK260LC-10 LL16-10001 02/19- Hino J05EUN-KSSD LQ10V00037F1
LQ10V00040F1		 LQ30V00051F1 LQ15V00038F2 LQ15V00037F1 LQ32W00021F2 LQ40F00021F1 LQ15V00031F3
Kobelco SK260LC-10E   11/19- Hino J05EVB-KSDA
Kobelco SK300LC-10 LB08-00101 3/17- Hino J08EVV-KSDP LB10V00011F1
LB10V00015F1		 LB30V00019F1 LB15V00024F1 LB15V00023F1 LC32W00016F1 LB40F00013F1 LC15V00045F1
Kobelco SK300LC-10E LB08005001 11/18- Hino J08EYD-KSDL LB10V00011F1
LB10V00015F1		 LB30V00019F2 LB15V00024F1 LB15V00023F1 LC32W00016F1 LB40F00013F1 LC15V00045F1
Kobelco SK350LC-10 YC14-14001 6/18- Hino J08EVV-KSDK LC10V00047F1
LC10V00050F1		 LC30V00051F1 LC15V00043F1 LC15V00042F1 LC32W00016F1 LC40F00027F1 LC15V00041F1
Kobelco SK350LC-10E YC14020001 11/18- Hino J08EYD-KSDA LC10V00047F1
LC10V00050F1		 LC30V00051F1 LC15V00043F1 LC15V00042F1 LC32W00016F1 LC40F00027F1 LC15V00041F1
Kobelco SK350DLC-10   10/18- Hino J08EVV-KSDK
Kobelco SK400DLC-10   10/18- Hino J08EVV-KSDK
Kobelco SK500-10 LS14-03501 10/19- Hino P11CVN-KSDH LS10V00030F1
LS10V00038F1		 LS30V00029F1 LS15V00037F1
LS15V00038F1		 LS15V00041F1
LS15V00041F1		 LS32W00020F1
LS32W00020F1		 LS40F00008F1 LS15V00020F4
Kobelco SK500LC-10 YS14-05001 10/19- Hino P11CVN-KSDH LS10V00030F1
LS10V00038F1		 LS30V00029F1 LS15V00037F1
LS15V00038F1		 LS15V00041F1
LS15V00041F1		 LS32W00020F1
LS32W00020F1		 LS40F00008F1 LS15V00020F4
Kobelco SK550DLC-10   10/18- Hino P11CVN
Kobelco SK850LC-10E LY04005001 3/19- Hino E13CYM-KSDB LV30P00014F1
LV10V00008F2		 LV30V00009F1 LV15V00012F1
LV15V00013F1		 LV15V00014F1
LV15V00014F1		 LV32W00005F1
LV32W00005F1		 LV40F00003F2 LV15V00001F1
LV53D00006F4
Kobelco -11 Excavators
Kobelco SK130LC-11 LP10030001 12/19- Isuzu VD-4JJ1XBSK-01 YY10V00027F2
YY10V00028F2		 YY30V00097F1 YY15V00039F1 YY15V00048F1 YY32W00015F1 LP40F00004F2 YY15V00041F1
Kobelco SK210LC-11 YN17010001   Hino J05EVA-KSSA YN10V00075F1
YN10V00079F1		 YN30V00180F1 YN15V00078F1 YN15V00077F1 YN32W00025F1 YN40F00042F2 YN15V00081F2
Kobelco SK210LC-11E YN17020001   Yanmar 4TN107FTT-4WYBE YN10V00075F1
YN10V00079F1		 YN30V00180F1 YN15V00078F1 YN15V00077F1 YN32W00025F1 YN40F00042F2 YN15V00081F2
Kobelco SK260LC-11 LQ18020001   Hino J05EVB-KSSA LQ10V00037F1
LQ10V00040F1		 LQ30V00056F1 LQ15V00038F2 LQ15V00037F2 LQ32W00021F2 LQ40F00021F2 LQ15V00039F2
Kobelco SK300LC-11 LB10006001   Hino J08EYD-KSSL LB10V00011F1
LB10V00015F2		 LB30V00025F1 LB15V00024F1 LB15V00023F1 LC32W00016F1 LB40F00013F1 LB53D00018F1
Kobelco SK300LC-11E LB10010001   Isuzu 6HK1XBSK-01 LB10V00019F1
LB10V00024F1		 LB30V00025F1 LB15V00024F1 LB15V00023F1 LC32W00016F1 LB40F00013F1 LB53D00018F1
Kobelco SK350LC-11 LC16025001   Hino J08EYD-KSSA LC10V00047F1
LC10V00050F1		 LC30V00058F1 LC15V00043F1 LC15V00042F1 LC32W00016F1 LC40F00027F1 LC15V00041F1
Kobelco SK500LC-11   4/21- Hino E13CYM
Kobelco SK530LC-11   4/21- Hino E13CYM
Kobelco SK Mini Excavators
Kobelco SK014 PU00750 9/02-12/03   S19020-09800 S19010-29100 S19031-07200     S19130-03950 S19031-06400
Kobelco SK015 PU02001 1/98-12/03   S19020-11900 S19010-30000 S19031-12700     S19130-03950
Kobelco SK024 PV00003 1/89-12/03   S19020-09500 S19010-24700 S19031-06500     S19130-02900 S19031-06800
Kobelco SK024 PV02600 1/89-12/03   S19020-09500 S19010-28700 S19031-09500     S19130-03600 S19031-08400
Kobelco SK025 PV04301 1/98-12/03   S19020-12000 S19010-30600 S19031-13200     S19130-03600 S19031-13400
Kobelco SK025-2 PV06201 3/01-9/04   PV10V00001F1 PV30V00005F1 PV15V00001F1     PV40F00005F1 PV15V00002F1
Kobelco SK030 PW03001 1/95-12/03   S19020-12200 S19010-30700 S19031-13100     S19130-03600 S19031-13600
Kobelco SK030-2 PW04401 1/03-12/04   PW10V00001F1 PW30V00003F1 PW15V00001F1     PV40F00005F1 PV15V00002F1
Kobelco SK035 PX01201 1/95-12/03   S19020-12300 S19010-30800 S19031-13000     S19130-03700 S19031-13700
Kobelco SK035-2 PX02101 1/98-12/03   PX10V00001F1 PX30V00002F1 PX15V00001F1     PX40F00005F1 PX15V00002F1
Kobelco SR, SR-1, SR-2 Mini Excavators
Kobelco SK08-1E   11/18- Yanmar 2TE67L-BV3
Kobelco SK09SR PA02-00101   Yanmar 2TN68-YB PA10V00001F1 PA30V00001F1 PA15V00001F1     PA40F00003F1 PA15V00002F1
Kobelco SK09SR PA02-01827   Yanmar 2TN68-YB PA10V00001F1 PA30V00001F3 PA15V00001F1     PA40F00003F1 PA15V00002F1
Kobelco SK10SR-2 PA03-06967 5/09- Yanmar 2TNV70-WYB PA10V00001F1 PA30V00017F4 PA15V00001F1     PF40F00001F1 PA15V00002F1
Kobelco SK10SR-2E PA03-07160 5/09- Yanmar 2TNV70-WYB PA10V00001F1 PA30V00017F4 PA15V00001F1     PF40F00001F1 PA15V00002F1
Kobelco SK13SR PE01-00101 1/00-12/03 Yanmar 3TN68-YB PE10V00001F1 PE30V00002F1 PE15V00001F1     PE40F00001F1 PE15V00005F1
Kobelco SK15SR PU06001 9/02-12/03 Yanmar 3TNE72L-UYBB PU10V00002F1 PU30V00006F2 PU15V00005F1     PU40F00003F1 PU15V00006F1
Kobelco SK15MSR PF02-02001   Yanmar 3TN68-YB PE10V00001F1 PE30V00004F1 PE15V00001F1     PA40F00003F1 PE15V00004F1
Kobelco SK16MSR PF02-02001   Yanmar 3TN68-YB PE10V00001F1 PE30V00004F1 PE15V00001F1     PA40F00003F1 PE15V00004F1
Kobelco SK16 PF03-03001   Yanmar 3TNE74-ENYBC PE10V00001F1 PF30V00004F1 PE15V00001F1     PF40F00001F1 PE15V00004F1
Kobelco SK17 PF03-03001   Yanmar 3TNE74-ENYBC PE10V00001F1 PF30V00004F1 PE15V00001F1     PF40F00001F1 PE15V00004F1
Kobelco SK18-1E   11/18- Yanmar 3TNV70-VBVA2
Kobelco SK20SR PM02001   Yanmar 3TNE72L-UYB PM10V00011F1 PM30V00017F1 PM15V00011F1     PM40F00011F1 PM15V00012F1
Kobelco SK20SR PM03501   Yanmar 3TNE72L-UYB PM10V00011F1 PM30V00017F1 PM15V00011F1     PM40F00011F1 PM15V00016F1
Kobelco SK22-1E   11/18- Yanmar 3TNV76-SBVA2
Kobelco SK25SR PV10001 1/98-12/04 Yanmar 3TNE78A-YBB PV10V00003F1 PV30V00020F1 PV15V00010F1     PV40F00006F1 PV15V00008F1
Kobelco SK25SR PV12001 1/98-12/04 Yanmar 3TNE78A-YBB PV10V00003F1 PV30V00021F1 PV15V00010F1     PV40F00006F1 PV15V00014F1
Kobelco SK25SR-2 PV08-20001 1/01-12/04 Yanmar 3TNE74-NYBB PM10V00013F1 PV30V00022F1 PM15V00014F1     PM40F00014F1 PV15V00019F1
Kobelco SK25SR-2 PV09-22001 3/01-12/04 Yanmar 3TNE74-NYBB PM10V00013F2 PV30V00032F1 PM15V00017F1     PM40F00014F1 PM15V00015F1
Kobelco SK26-1E   11/18- Yanmar 3TNV82A-BPBVA
Kobelco SK30SR PW03501 1/03-12/04 Yanmar 3TNE82A-YB PW10V00011F1 PW30V00021F1 PW15V00011F1     PW40F00002F1 PW15V00014F1
Kobelco SK30SR PW07001 1/03-12/04 Yanmar 3TNE82A-YB PW10V00012F1 PW30V00021F1 PW15V00011F2     PW40F00002F1 PW15V00015F1
Kobelco SK30SR-2 PW08-20001 3/01-9/04 Yanmar 3TNE82A-YBC PW10V00013F1 PW30V00022F1 PW15V00016F1     PW40F00002F2 PW15V00018F1
Kobelco SK30SR-2 PW10-22001 1/03- Yanmar 3TNE82A-EYBC PW10V00013F1 PW30V00022F4 PW15V00016F2     PW40F00002F2 PW15V00018F3
Kobelco SK35SR PX05001 1/04-12/04 Yanmar 3TNE84-YBD PX10V00004F1 PX30V00017F1 PX15V00008F1     PW40F00002F1 PX15V00006F1
Kobelco SK35SR PX06501 1/04-12/04 Yanmar 3TNE82A-YBB PX10V00008F1 PX30V00021F1 PX15V00011F1     PW40F00002F1 PX15V00015F1
Kobelco SK35SR-2 PX09-08001 1/03-12/04 Yanmar 3TNE82A-YBD PW10V00013F2 PX30V00022F1 PX15V00018F1     PW40F00002F2 PX15V00019F1
Kobelco SK35SR-2 PX11-08901 1/04- Yanmar 3TNE82A-EYBD PW10V00013F2 PX30V00022F3 PX15V00018F2     PW40F00002F2 PX15V00019F3
Kobelco SK40SR-2 PH03-02001   Yanmar 4TNE84-YB PH10V00004F1 PH30V00031F1 PH15V00007F1     PY40F00001F2 PH15V00009F3
Kobelco SK40SR-2 PH04-02801 1/90-12/04 Yanmar 4TNE84-YB PH10V00004F1 PH30V00019F2 PH15V00007F1     PY40F00001F2 PH15V00009F3
Kobelco SK45SR PY06001 1/90-12/04 Yanmar 4TNE88-YBB PY10V00007F1 PY30V00003F1 PY15V00004F1     PY40F00001F1 PY15V00005F1
Kobelco SK45SR PY07101 1/90-12/04 Yanmar 4TNE88-EYBB PY10V00007F1 PY30V00003F3 PY15V00004F1     PY40F00001F1 PY15V00006F1
Kobelco SK45SR-2 PJ02-00101 1/01-12/04 Yanmar 4TNE88-(E)YBC PY10V00009F1 PY30V00022F1 PY15V00007F1     PY40F00001F2 PY15V00009F2
Kobelco SK45SR-2 PJ03-01001 1/03-12/04 Yanmar 4TNE84-YB PY10V00009F1 PY30V00012F2 PY15V00007F1     PY40F00001F2 PY15V00009F3
Kobelco SR-3, SR-5, SR-6 Mini Excavators
Kobelco SK17SR-3 PU09-08001 3/07-12/13   PU10V00014F1 PU30V00017F2 PU15V00019F1     PF40F00001F1 PU15V00021F1
Kobelco SK17SR-3E PU11-13001 1/19- Yanmar 3TNV70-SYB PU10V00014F1 PU30V00017F2 PU15V00019F1     PF40F00001F1 PU15V00018F1
Kobelco SK20SR-3 PU09-08001 6/04-12/04   PM10V00017F1 PM30V00036F1 PM15V00020F1     72283088 PM15V00022F1
Kobelco SK25SR-6E   11/18- Yanmar 3TNV76-NBVA1
Kobelco SK27SR-5 PV13-33453 6/04-12/12 Yanmar 3TNV82A PM10V00017F1 PM30V00051F2 PM15V00020F1     PM40F00014F1 PM15V00021F1
Kobelco SK28SR-6   5/15- Yanmar 3TNV82A-BPYB
Kobelco SK28SR-6E   10/18- Yanmar 3TNV82A-B
Kobelco SK30SR-3   6/04-12/04   PX10V00013F1 PX30V00041F2 PX15V00024F1     PW40F00004F2 PX15V00025F1
Kobelco SK30SR-5 PW14-45001 1/08-12/11 Yanmar 3TNV88 PX10V00012F1 PX30V00041F4 PX15V00024F1     PW40F00006F1 PX15V00025F1
Kobelco SK30SR-6 PW15-50001 5/15- Yanmar 3TNV82A-BPYB PX10V00023F1 PW30V00050F1 PX15V00029F1     PX40F00008F1 PX15V00027F1
Kobelco SK30SR-6E   10/18- Yanmar 3TNV82A-B
Kobelco SK35SR-5 PX15-21105 1/08-12/13 Yanmar 3TNV88 PX10V00013F1 PX30V00041F4 PX15V00024F1     PW40F00006F1 PX15V00025F1
Kobelco SK35SR-6 PX16-30001 5/15- Yanmar 3TNV82A-BPYB PX10V00023F1 PW30V00050F4 PX15V00029F3     PX40F00008F1 PX15V00027F1
Kobelco SK35SR-6E   10/18- Yanmar 3TNV82A-B
Kobelco SK40SR-3   6/04-12/04 Yanmar 4TNV88-XYB PH10V00010F3 PH30V00042F3 PY15V00012F1     72284216 PH15V00012F1
Kobelco SK45SRX-6 PH08- 8/15- Yanmar 4TNV88-BPYB
Kobelco SK45SRX-6E   8/20- Yanmar 4TNV88C-PYBV
Kobelco SK50SR-3 PJ04-03001 1/05-12/06 Yanmar 4TNV88 PH10V00008F1 PY30V00035F1 PY15V00012F1     PH40F00004F1 PH15V00012F1
Kobelco SK50SR-5 PJ06-08001 1/05-12/11 Yanmar 4TNV88 PH10V00013F1 PH30V00051F3 PY15V00012F1     PH40F00004F1 PH15V00012F1
Kobelco SK55SRX-5 PS02-00101 10/11-12/13   PH10V00013F1 PY30V00063F1 PY15V00014F1     PY40F00002F1 PH15V00012F1
Kobelco SK55SRX-6 PS03-06936 8/15- Yanmar 4TNV88-BPYB PS10V00002F1 PS30V00002F1 PS15V00004F1     PS40F00003F1 PS15V00003F1
Kobelco SK55SRX-6E   8/20- Yanmar 4TNV88C-PYBV
Kobelco SR, SR-1, SR-2 Excavators
Kobelco SK70SR YT01-00101 1/99-12/04 Isuzu A-4JB1PYA-03 YT10V00003F1 YT30V00010F1 YT15V00001F2 YT15V00005F2 YT32W00002F1 2425U261F1 YT15V00002F1
Kobelco SK70SR-1E YT02-04001 1/02-8/08 Isuzu CC-4JG1PYA YT10V00001F2 YT30V00010F3 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 YT15V00008F1
Kobelco SK70SR-1E YT03-05432 1/02-8/08 Isuzu CC-4JG1PYA YT10V00001F2 YT30V00010F3 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 YT15V00008F1
Kobelco SK70SR-1ES YT04-07001 1/04-12/04 Isuzu CC-4JG1PYA-01 YT10V00008F1 YT30V00010F4 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 YT15V00008F1
Kobelco SK70SR-2 YT06-18001 10/10-1/13 Isuzu AU-4LE2X YT10V00008F1 YT30V00014F4 YT32W00003F1 YT15V00015F1 YT32W00006F1 YT40F00004F1 YT15V00012F1
Kobelco SK80MSR LF01-00501 1/01-12/04 Isuzu A-4JB1PYA-03 YT10V00002F1 LF30V00001F1 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 LF15V00002F1
Kobelco SK80MSR-1E LF02-01001 1/03-12/05 Isuzu CC-4JG1PYA YT10V00002F2 LF30V00002F1 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 YT15V00008F1
Kobelco SK80MSR-1E LF03-01280 1/03-12/05 Isuzu CC-4JG1PYA YT10V00002F2 LF30V00002F1 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 YT15V00008F1
Kobelco SK80MSR-1ES LF04-02001 1/03-12/05 Isuzu CC-4JG1PYA-01 YT10V00009F1 LF30V00002F1 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 YT15V00008F1
Kobelco SK80CS LF05-04001 1/02-12/08 Isuzu AU-4LE2X YT10V00009F1 YT30V00039F1 YT15V00015F1 YT15V00016F1 YT32W00006F1 YT40F00004F1 YT15V00012F1
Kobelco SK80CS-2 LF06-04501 7/02-9/08 Isuzu AU-4LE2X YT10V00023F1 LF30V00005F4 YT15V00015F1 YT15V00016F1 YT32W00006F1 YT40F00004F1 YT15V00012F2
Kobelco SK115SR YV01-00101 1/99-12/06 Isuzu A-4BG1PY-01 YV10V00001F1 YV30V00010F1 YV15V00001F1 YV15V00002F1 YX32W00002F1 24100N7529F1 YX15V00003F1
Kobelco SK115SR-1E YV02-01701 1/99-12/06 Isuzu BB-4BG1TRY-01 YV10V00001F2 YV30V00013F1 YV15V00001F2 YV15V00002F2 YX32W00002F2 24100N7529F1 YX15V00003F2
Kobelco SK115SR-1ES YV04-03001 1/99-12/06 Isuzu BB-4BG1TRY-01 YV10V00001F4 YV30V00013F1 YV15V00001F3 YV15V00002F3 YX32W00002F3 24100N7529F2 YX15V00003F4
Kobelco SK135SR YY01-00101 1/99-12/06 Isuzu A-4BG1TPY-01 YY10V00001F1 YY30V00001F1 YX15V00002F1 YX15V00004F1 YX32W00002F1 24100N7529F1 YX15V00003F1
Kobelco SK135SRL LK01-01001 1/99-12/06 Isuzu A-4BG1TPY-01 YY10V00001F1 YY30V00001F1 YX15V00002F1 YX15V00004F1 YX32W00002F1 24100N7529F1 2441U994F3
Kobelco SK135SRLC YH01-00101 1/99-12/06 Isuzu A-4BG1TPY-02 YY10V00001F1 YY30V00001F1 YX15V00002F1 YX15V00004F1 YX32W00002F1 24100N7529F1 YX15V00003F1
Kobelco SK135SR-1E YY02-03001 1/99-12/06 Isuzu BB-4BG1TRY YY10V00001F2 YY30V00036F1 YX15V00002F2 YX15V00005F2 YX32W00002F2 24100N7529F1 YX15V00003F2
Kobelco SK135SRL-1E LK02-01101 1/99-12/06 Isuzu BB-4BG1TRY YY10V00001F2 YY30V00036F1 YX15V00002F2 YX15V00005F2 YX32W00002F2 24100N7529F1 2441U994F3
Kobelco SK135SRLC-1E YH02-01301 1/99-12/06 Isuzu BB-4BG1TRY YY10V00001F2 YY30V00041F1 YX15V00002F2 YX15V00005F2 YX32W00002F2 24100N7529F1 YX15V00003F2
Kobelco SK135SR-1ES YY04-06001 1/99-12/06 Isuzu BB-4BG1TRY YY10V00001F4 YY30V00036F1 YX15V00002F3 YX15V00005F3 YX32W00002F2 24100N7529F2 YX15V00003F4
Kobelco SK135SRLC-1ES YH04-03001 1/99-12/06 Isuzu BB-4BG1TRY YY10V00001F4 YY30V00041F1 YX15V00002F3 YX15V00005F3 YX32W00002F2 24100N7529F2 YX15V00003F4
Kobelco SK135SR-2 YY05-12001 1/08-12/12 Mitsubishi D04FD-TAA YY10V00009F1 YY30V00058F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00015F1
Kobelco SK135SRLC-2 YH05-07001 1/08-12/12 Mitsubishi D04FD-TAA YY10V00009F1 YY30V00058F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00015F1
Kobelco SK140SRLC YH05-07001 1/08-12/12 Mitsubishi D04FD-TAA YY10V00009F1 YY30V00058F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00011F1 YY15V00015F1
Kobelco SK140SRLC YH06-08001 9/10-12/12 Mitsubishi D04EG-TAA YY10V00009F4 YY30V00058F2 YY15V00021F1   YY32W00003F2 YY40F00011F2 YY15V00015F1
Kobelco SK200SR YB01-01001 1/01-12/03 Isuzu AA-4BG1TC YB10V00001F1 YB30V00004F1 YN15V00001F1 YN15V00002F4 YB32W00001F1 YB40F00001F1 YN15V00011F1
Kobelco SK200SRLC LA01-01001 1/01-12/01 Isuzu AA-4BG1TC YB10V00001F1 YB30V00004F1 YN15V00001F1 YN15V00002F4 YB32W00001F1 YB40F00001F1 YN15V00011F1
Kobelco SK200SR YB02-01601 1/01-12/03 Isuzu AA-4BG1TC YB10V00001F2 YB30V00010F1 YN15V00006F1 YN15V00005F1 YB32W00001F1 YB40F00001F1 YN15V00011F2
Kobelco SK200SRLC LA02-01201 1/01-12/06 Isuzu AA-4BG1TC YB10V00001F2 YB30V00010F1 YN15V00006F1 YN15V00005F1 YB32W00001F1 YB40F00001F1 YN15V00011F2
Kobelco SK200SR YB03-02050 1/03-12/04 Isuzu AA-4BG1TC YB10V00001F3 YB30V00011F1 YN15V00006F1 YN15V00005F1 YB32W00001F1 YB40F00001F1 YN15V00011F3
Kobelco SK200SRLC LA03-01237 1/01-12/06 Isuzu AA-4BG1TC YB10V00001F4 YB30V00011F1 YN15V00006F1 YN15V00005F1 YB32W00001F1 YB40F00001F1 YN15V00011F3
Kobelco SK200SR-1S YB04-02301 1/03-12/04 Isuzu AA-4BG1TC YB10V00001F5 YB30V00012F1 YB15V00001F2 YN15V00025F4 YB32W00001F1 YB40F00001F2 YN15V00011F4
Kobelco SK200SRLC-1S LA04-01501 1/03-12/04 Isuzu AA-4BG1TC YB10V00001F6 YB30V00012F1 YB15V00001F2 YN15V00025F4 YB32W00001F1 YB40F00001F2 YN15V00011F4
Kobelco SK215SRLC LA05-02001 8/07-12/11 Hino J05E-TG YF10V00006F1 YB30V00021F1 YB15V00012F2 YB15V00011F1 YB32W00010F1 YB40F00011F1 YN15V00037F1
Kobelco SK215SRLC LA06-02501 1/11-12/11 Hino J05E-TG YF10V00006F2 YB30V00021F4 YB15V00012F3 YB15V00011F1 YB32W00010F2 YB40F00011F1 YN15V00037F2
Kobelco SK235SR YF01-00101 1/99-12/06 Mitsubishi 6D34-TEA YN10V00008F1 YN30V00032F2 YN15V00013F1 YN15V00012F1 YN32W00004F2 YN40F00007F1 LQ15V00007F1
Kobelco SK235SRLC YU01-00101 1/00-12/00 Mitsubishi 6D34-TEA YN10V00008F1 YN30V00032F2 YN15V00013F1 YN15V00012F1 YN32W00004F2 YN40F00007F1 LQ15V00007F1
Kobelco SK235SR-1E YF02-01201 1/03-12/04 Mitsubishi 6D34-TLU2A YF10V00002F1 YF30V00003F1 YF15V00001F1 YF15V00002F1 LQ32W00009F2 YF40F00001F1 LQ15V00007F2
Kobelco SK235SRLC-1E YU02-00501 1/03-12/04 Mitsubishi 6D34-TLU2A YF10V00002F1 YF30V00003F1 YF15V00001F2 YF15V00002F2 LQ32W00009F2 YF40F00001F1 LQ15V00007F2
Kobelco SK235SR-1E YF03-01300 10/03-12/03 Mitsubishi 6D34-TLU2D YF10V00002F2 YF30V00003F1 YF15V00001F2 YF15V00002F2 LQ32W00009F2 YF40F00001F1 LQ15V00019F1
Kobelco SK235SRLC-1E YU03-00648 10/03-12/03 Mitsubishi 6D34-TLU2D YF10V00002F2 YF30V00003F1 YF15V00001F2 YF15V00002F2 LQ32W00009F2 YF40F00001F1 LQ15V00019F1
Kobelco SK235SR-1ES YF04-01501 1/01-12/06 Mitsubishi 6D34-TLU2D YF10V00002F2 YF30V00002F1 YF15V00001F2 YF15V00002F2 LQ32W00009F2 YF40F00002F1 LQ15V00019F1
Kobelco SK235SRLC-1ES YU04-00801 1/01-12/06 Mitsubishi 6D34-TLU2D YF10V00002F2 YF30V00002F1 YF15V00001F2 YF15V00002F2 LQ32W00009F2 YF40F00002F1 LQ15V00019F1
Kobelco SK235SR-2 YF05-02001 3/07-12/11 Hino J05E-TG YF10V00006F1 YN30V00101F2 YF15V00003F1 YF15V00004F1 YF32W00001F1 YF40F00007F1 LQ15V00020F1
Kobelco SK235SRLC-2 YU05-02001 1/01-12/06 Hino J05E-TG YF10V00006F1 YN30V00101F2 YF15V00003F1 YF15V00004F1 YF32W00001F1 YF40F00007F1 LQ15V00020F1
Kobelco SK235SRLC-2 YU06-03001 1/01-12/06 Hino J05E-TG YF10V00006F2 YN30V00101F5 YF15V00003F1 YF15V00004F1 YF32W00001F1 YF40F00007F2 LQ15V00020F3
Kobelco SR-3, SR-5, SR-7 Excavators
Kobelco SK75SR-3 YT08-30001 1/12-12/13 Isuzu 4LE2X-S YT10V00027F1 YT30V00065F1 YT15V00015F3 YT15V00016F3 YT32W00006F1 YT40F00007F1 YT15V00019F1
Kobelco SK75SR-3E YT08-30001   Isuzu 4LE2XDPA YT10V00027F2 YT30V00065F1 YT15V00015F3 YT15V00016F3 YT32W00006F1 YT40F00007F1 YT15V00019F1
Kobelco SK75SR-7 YT09-40001 10/18- Yanmar 4TNV98CT-L2VYB YT10V00038F1 YT30V00101F1 YT15V00015F4 YT15V00016F4 YT32W00006F1 YT40F00014F1 YT15V00022F1
Kobelco SK75SR-7 YT09045001 10/18- Yanmar 4TNV98CT-L2VYB YT10V00038F1 YT30V00101F1 YT15V00015F4 YT15V00016F4 YT32W00006F1 YT40F00014F1 YT15V00022F1
Kobelco SK85MSR-3E LF08-05501 1/15- Isuzu 4LE2XDPA YT10V00027F2 YT30V00081F1 YT15V00015F3 YT15V00016F3 YT32W00006F1 YT40F00007F1 YT15V00019F2
Kobelco SK85MSR-7 LF09-08001 10/18- Yanmar 4TNV98CT-L2VYB YT10V00038F1 YT30V00106F1 YT15V00015F4 YT15V00016F4 YT32W00006F1 YT40F00014F1 YT15V00022F1
Kobelco SK85MSR-7 LF09010001 10/18- Yanmar 4TNV98CT-L2VYB YT10V00038F1 YT30V00106F1 YT15V00015F4 YT15V00016F4 YT32W00006F1 YT40F00014F1 YT15V00022F1
Kobelco SK140SRLC-3 YH07-09001 6/12-12/13 Mitsubishi D04EG-TAA YY10V00013F5 YY30V00077F1 YY15V00028F1 YY15V00034F1 YY32W00004F1 YY40F00018F1 YY15V00015F1
Kobelco SK140SRL-5 LK08-02501 3/17- Isuzu AR-4JJ1XASK-01 YY10V00028F2 YY30V00078F2 YY15V00037F1 YY15V00034F2 YY32W00004F1 YY40F00018F1 LP15V00006F2
Kobelco SK140SRLC-5 YH08-11001 3/17- Isuzu AR-4JJ1XASK-01 YY10V00028F2 YY30V00078F2 YY15V00037F1 YY15V00034F2 YY32W00004F1 YY40F00018F1 YY15V00035F1
Kobelco SK140SRLC-7 YY09045001 12/19- Isuzu VD-4JJ1XBSK-01 YY10V00028F2 YY30V00099F1 YY15V00040F1 YY15V00049F1 YY32W00015F1 YY40F00018F1 YY15V00041F1
Kobelco SK225SR-5   6/16- Hino J05EUM-KSSL
Kobelco SK230SR-3 LA07-03001 11/12-12/13 Hino J05ETJ-KSDR YF10V00006F3 YB30V00024F1 YB15V00018F1 YB15V00017F1 YB32W00012F1 YB40F00011F1 YN15V00051F5
Kobelco SK230SRLC-5 LA08-04001 6/16- Hino J05EUM-KSSL YF10V00013F1
YF10V00017F1		 YB30V00026F1 YB15V00018F2 YB15V00017F2 YB32W00012F1 YB40F00011F1 YN15V00051F6
Kobelco SK230SRLC-5E     Hino J05EVA-KSDS
Kobelco SK230SRLC-7 YB09015001   Yanmar 4TN107FTT-4WYBD YF10V00013F1
YF10V00017F1		 YB30V00026F1 YF15V00010F1 YF15V00009F1 YF32W00007F1 YB40F00011F1 YN15V00081F2
Kobelco SK230SRLC-7 YB09015050   Yanmar 4TN107FTT-4WYBD YF10V00013F1
YF10V00017F1		 YN30V00129F2 YF15V00010F1 YF15V00009F1 YF32W00007F1 YB40F00011F1 YN15V00081F2
Kobelco SK260SRLC-3 YU07-04001 11/12-12/13 Hino J05ETJ-KSDR YF10V00006F3 YN30V00126F1 YF15V00005F1   YF32W00005F1 YF40V00007F2 LQ15V00031F4
Kobelco SK270SRLC-5 YU08-05001 6/16- Hino J05EUM-KSSL YF10V00013F1
YF10V00017F1		 YB30V00129F2 YF15V00010F1 YF15V00009F1 YF32W00007F1 YB40F00010F1 LQ15V00031F4
Kobelco SK270SRLC-5E     Hino J05EVA-KSDS
Kobelco SK270SRLC-7 YF09015001   Yanmar 4TN107FTT-4WYBD YF10V00013F1
YF10V00017F1		 YN30V00129F2 YF15V00010F1 YF15V00009F1 YF32W00007F1 YF40F00013F1 LQ15V00039F2
Kobelco SK380SRLC     Hino J08EYD
Kobelco SK380SRLC-7 LR02000501   Isuzu 6HK1XASK-01 LB10V00016F1
LB10V00019F1		 LR30V00001F1 LC15V00043F2 LC15V00042F2 LC32W00016F1 LR40F00002F1 LC15V00045F2
LC53D00027F2
Kobelco Blade Runner Excavators
Kobelco ED150 YH02-01384 4/02-12/03 Isuzu A-4BG1T YY10V00005F1 YY30V00044F1         YY15V00006F1
Kobelco ED150 YL04-00501 4/03-10/03 Isuzu A-4BG1T YY10V00005F1 YY30V00044F1   YY15V00005F1 YX32W00002F2 YY40F00004F1 YY15V00006F1
Kobelco ED150-1E YL05-00555 4/02-12/03 Isuzu A-4BG1T YY10V00005F1 YY30V00044F1   YY15V00005F1 YX32W00002F2 LP40F00002F1 YY15V00006F1
Kobelco ED150 YL06-01201 5/08-12/12 Mitsubishi D04FD-TAA YY10V00016F1 YY30V00058F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00006F2
Kobelco ED150-2 LH01-01001 1/09-12/12 Mitsubishi D04FD-TAA YY10V00016F3 YY30V00077F1 YY15V00021F1   YY32W00003F2 YY40F00009F1 YY15V00006F2
Kobelco ED160 LH02-01501 9/12-12/13 Mitsubishi D04EG-TAA YY10V00016F3 YY30V00077F1 YY15V00022F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00006F2
Kobelco ED160BR-5 LH03-02001 3/17- Isuzu AR-4JJ1XASK-01 YY10V00030F2 YY30V00077F2 YY15V00037F1 YY15V00034F2 YY32W00004F1 YY40F00018F1 YY15V00036F3
Kobelco ED160BR-7 LH04006001   Isuzu AR-4JJ1XDRAC-01 YY10V00030F2 YY30V00097F1 YY15V00040F1 YY15V00049F1 YY32W00015F1 YY40F00019F1 YY15V00046F1
Kobelco ED180 YLU0001 1/99-12/01 Mitsubishi 4D34-TEG 2437U542F2 2436U2905F1 24100J16122F3 2441U819F3   24100N8102F1 2441U1053F1
Kobelco ED190LC-6 YL02U-0101 1/02-12/06 Mitsubishi 4D34-TEG YM10V00001F1 YM30V00001F1 YM15V00002F1 YN15V00002F4 YM32W00001F1 YM40F00001F1 2441U1053F1
Kobelco ED190LC-6 YL03U-0136 1/05-12/06 Mitsubishi 4D34-TEG YM10V00001F3 YM30V00006F1 YM15V00003F1 YN15V00025F1 YM32W00001F1 YM40F00001F1 2441U1054F1
Kobelco ED195-8 YL04U-0301 12/07-12/11 FPT F4GE9484D*J6 YM10V00005F1 YM30V00011F1 YM15V00004F2 YM15V00006F1 YM32W00008F1 YM40F00006F1 YM15VU0002F1
New Holland Mini Excavators
New Holland E9SR PA02-02621 1/05- Yanmar 2TN68-YB 72953644 72953677 PA15V00001F1     PF40F00001F1 PA15V00002F1
New Holland E10SR PA03-05001 1/10- Yanmar 2TNV70-WYB PA10V00001F1 PA30V00017F2 PA15V00001F1     PF40F00001F1 PA15V00002F1
New Holland E16   1/05- Yanmar 3TNE74-ENYBC PE10V00001F1 72274560 72271587     72271600 72271598
New Holland E16   1/05- Yanmar 3TNE74-ENYBC PE10V00001F1 87360433 87388739     72271600 72271598
New Holland E16   1/05- Yanmar 3TNE74-ENYBC PE10V00001F1 72276961 72276962     72271600 72271598
New Holland E16B   2/08- Mitsubishi LE-W431KB 72271592 72276961 87595383     87618256 72271598
New Holland E16B   1/11- Yanmar 3TNV88-PYB 72271592 72276961 87595383     87618256 72271598
New Holland E18   1/05- Yanmar 3TNE74-ENYBC PE10V00001F1 72274560 72271587     72271600 72271598
New Holland E18   1/05- Yanmar 3TNE74-ENYBC PE10V00001F1 87360433 87388739     72271600 72271598
New Holland E18   1/05- Yanmar 3TNE74-ENYBC PE10V00001F1 72276961 72276962     72271600 72271598
New Holland E18SR PU08-05001 3/08- Mitsubishi W231KBS PU10V00014F1 PU30V00017F1 PU15V00019F1     PF40F00001F1 PU15V00018F1
New Holland E18SR PU09-08001 5/10- Mitsubishi W231KBS PU10V00014F1 PU30V00017F2 PU15V00019F1     PF40F00001F1 PU15V00018F1
New Holland E18B   2/08- Mitsubishi LE-W431KBSA 87595308 87595384 87595383     87618256 72271598
New Holland E18B   1/11- Yanmar 3TNV88-PYB 87595308 87595384 87595383     87618256 72271598
New Holland E20.2SR PM07-07329 1/05- Yanmar 3TNV82A-SYB PM10V00017F1 PM30V00036F1 PM15V00020F1     72283088 72282278
New Holland E20.2SR N5GN01561 10/05- Yanmar 3TNV82A-SYB PM10V00017F1 87704798 PM15V00020F1     72283088 72282278
New Holland E22.2SR PM07-07329 1/05- Yanmar 3TNV82A-SYB PM10V00017F1 PM30V00036F1 PM15V00020F1     72283088 72282278
New Holland E22.2SR N5GN01561 10/05- Yanmar 3TNV82A-SYB PM10V00017F1 87704798 PM15V00020F1     72283088 72282278
New Holland E26B SR   3/11- Yanmar 3TNV88-PYB 72281552 87704798 72281553     72283088 72281630
New Holland E27.2SR PM10-27577 1/05- Yanmar 3TNV82A-SYB PM10V00017F1 PM30V00036F1 PM15V00020F1     72283088 72281630
New Holland E27.2SR N5GN01567 10/05- Yanmar 3TNV82A-SYB PM10V00017F1 87704798 PM15V00020F1     72283088 72281630
New Holland E29B SR   3/11- Yanmar 3TNV88-PYB 72281552 87704798 72281553     72283088 72281630
New Holland E30.2SR PW11-30850 1/05- Yanmar 3TNV88-PYB PX10V00013F1 PX30V00041F2 PX15V00024F1     72281139 72280157
New Holland E30.2SR N5GN01518 10/05- Yanmar 3TNV88-PYB PX10V00013F1 87704800 PX15V00024F1     72281139 72280157
New Holland E35.2SR PX12-11451 1/05- Yanmar 3TNV88-PYB PX10V00013F1 PX30V00041F2 PX15V00024F1     72281139 72280157
New Holland E35.2SR N5GN01498 10/05- Yanmar 3TNV88-PYB PX10V00013F1 87704800 PX15V00024F1     72281139 72280157
New Holland E35B SR   3/11- Yanmar 3TNV88-PYB 72282097 87704800 72280137     72281139 72280157
New Holland E39B SR   3/11- Yanmar 3TNV88-PYB 72282097 87704800 72280137     72281139 72280157
New Holland E40.2SR PH05-03907 1/05- Yanmar 3TNV88-PYB 72285151 87341195 PY15V00012F1     72284219 72284190
New Holland E40.2SR N5GN01228 10/05- Yanmar 3TNV88-PYB 72285151 87341195 PY15V00012F1     72284219 72284190
New Holland E45B SR   3/11- Yanmar 3TNV88-PYB 72285151 87341195 72283621     72284219 72284190
New Holland E50.2SR PJ04-03001 9/04-12/04 Yanmar 4TNV88-XYB 72283618 PY30V00032F2 PY15V00012F1     72284219 72284190
New Holland E50.2SR PJ04-03045 9/04-12/04 Yanmar 4TNV88-XYB 72285151 PY30V00032F2 PY15V00012F1     72284219 72284190
New Holland E50.2SR PJ04-03293 9/04-12/04 Yanmar 4TNV88-XYB 72285151 72285639 PY15V00012F1     72284219 72284190
New Holland E50.2SR PJ04-03492 9/04-12/04 Yanmar 4TNV88-XYB 72285151 87341221 PY15V00012F1     72284219 72284190
New Holland E50.2SR N5GN01203 10/05- Yanmar 4TNV88-XYB 72285151 87341221 PY15V00012F1     72284219 72284190
New Holland E50B SR   3/11- Yanmar 3TNV88-PYB 72285151 87341221 72283621     72284219 72284190
New Holland A Series Excavators
New Holland E70   1/98-12/03 Isuzu CC-4JG1-PYA YT10V00001F2 YT30V00010F3 YT15V00001F3 YT15V00005F2 YT32W00002F2 2425U261F1 YT15V00008F1
New Holland E70SR YT04-07001 1/05-12/07 Isuzu CC-4JG1-PYA-01 72151120 72150162   72950197 YT32W00002F2 2425U261F1 YT15V00008F1
New Holland E80MSR LF04-02001 8/04-12/07 Isuzu CC-4JG1-PYA-01 72150495 72957423   72950197 YT32W00002F2 2425U261F1 YT15V00008F1
New Holland E115SR YV03-03001 11/04-12/06 Isuzu BB-4BG1T 72150078 72958180 72150146 72150390 YX32W00002F2 87336605 72150092
New Holland E115SR YV03-03270 11/04-12/06 Isuzu BB-4BG1T 87336527 72958180 72150146 72150390 YX32W00002F2 87336605 72150092
New Holland E115SR YV03-03404 11/04-12/06 Isuzu BB-4BG1T 87336600 72958180 72150146 72150390 YX32W00002F2 87336605 72150092
New Holland E115SR YV04-03043 11/04-12/06 Isuzu BB-4BG1T YY10V00001F1 YV30V00013F1 YV15V00001F3 YV15V00003F1 YX32W00002F1 YY40F00006F3 YX15V00003F1
New Holland E135SR YY04-06001 11/02-12/08 Isuzu BB-4BG1T 72150078 72953813     72151433 24100N7529F2 72150092
New Holland E135SRLC YH04-03001 11/04-12/08 Isuzu BB-4BG1T 72150078 72953813     72151433 24100N7529F2 72150092
New Holland E135SR YY04-06679 11/02-12/08 Isuzu BB-4BG1T 87336527 72953813 YX15V00002F3 YX15V00005F3 YX32W00002F2 24100N7529F2 72150092
New Holland E135SRLC YH04-03457 11/02-12/08 Isuzu BB-4BG1T 87336527 72953813 YX15V00002F3 YX15V00005F3 YX32W00002F2 24100N7529F2 72150092
New Holland E135SR YY04-07317 11/02-12/08 Isuzu BB-4BG1T 87336600 72953813 YX15V00002F3 YX15V00005F3 YX32W00002F2 24100N7529F2 72150092
New Holland E135SRLC YH04-03776 11/02-12/08 Isuzu BB-4BG1T 87336600 72953813 YX15V00002F3 YX15V00005F3 YX32W00002F2 24100N7529F2 72150092
New Holland E145   1/05-12/10 Iveco F4BE0454B*D601 72214020 72206455 72214150 72214467 72214466 72219336 72214452
New Holland E150 YL05-00979 1/07-12/08 Isuzu BB-4BG1T YY10V00005F4 72953813 72151433 YX15V00005F3 YX32W00002F2 YY40F00006F3 YY15V00006F2
New Holland E175   1/05-12/07 Iveco F4BE0484E*D607 72204983 72205217 72204981 72203588   72200589 87357868
New Holland E195   9/04-12/04 Iveco F4BE0484D*D608 YB10V00001F1 72206457 72211270 72211912 72203590 72260052 87357869
New Holland E200SR YB04-02319 1/04-12/05 Isuzu AA-4BG1TCY YB10V00001F1 YB30V00011F1 YB15V00006F1 YB15V00005F1 YB32W00001F1 YB40F00001F2 YN15V00011F1
New Holland E200SRLC LA04-01501 1/04-12/05 Isuzu AA-4BG1TCY 72211269 72953976   72953965 YB32W00001F1 72150210 72150239
New Holland E200SRLC LA04-01506 1/04-12/05 Isuzu AA-4BG1TCY YB10V00001F1 YB30V00011F1 YB15V00006F1 YB15V00005F1 YB32W00001F1 YB40F00001F2 YN15V00011F4
New Holland E200SRLC LA04-01558 1/04-12/05 Isuzu AA-4BG1TCY 72151914 72953976   72953965 YB32W00001F1 72150210 72150239
New Holland E215   1/05-12/06 Iveco F4BE0684B*D402 72204145 72203576 72203589 72203588   72203516 72206512
New Holland E215 NALA02832 1/05-12/06 Iveco F4BE0684M*D600 72204145 72203576 72203589 72203588   72203516 72206512
New Holland E235SR LF04-01501 1/05-12/07 Mitsuvishi 6D34-TLU2D 72150711 72959705   72219425 72959608 87336608 72150719
New Holland E235SRLC YU04-00801 12/04-12/07 Mitsuvishi 6D34-TLU2D 72150711 72959705   72219425 72959608 87336608 72150719
New Holland E245   1/05-12/07 Iveco F4BE0684B*D402 72204145 72203576 72203589 72203588   72203516 72210201
New Holland E245 NALA02832 1/05-12/07 Iveco F4BE0684M*D600 72204145 72203576 72203589 72203588   72203516 72210201
New Holland E265   9/04-12/07 Iveco F4AE0684L*D101 72211797 72213195 72212978 72212979 72212980 72212986 72210201
New Holland E265 N6LA03877 12/05-12/07 CNH 667TA/EEG 72211797 72213195 72212978 72212979 72212980 72212986 72210201
New Holland E305   1/05-12/05 Iveco F4AE0684K*D101 72211800 72215986 72212982 72212983 72212984 72212986 72225043
New Holland E305 N6LA03921 1/05-12/05 CNH 667TA/EEC 72211800 72215986 72212982 72212983 72212984 72212986 72225043
New Holland E335 LC09-06523 1/05-12/06 Mitsubishi 6D16-TLU2D 87332949 87332953   87332952 72208950 87335991 87333433
New Holland E335 LC09-06624 1/05-12/06 Mitsubishi 6D16-TLU2D 87336571 87332953   87332952 72208950 87335991 87333433
New Holland E385   1/05-12/06 Isuzu 6HK1XQY 72208819 72210720 72209782 72208949 72208950 72208804 72214435
New Holland E385 N6LA03885 12/05-12/07 Isuzu 6HK1XYSK01 72208819 72210720 72209782 72208949 72208950 72208804 72214435
New Holland E485   10/05-12/07 Isuzu 6SD1XQY 72216529 72216543 72216533
72216532		 72216690
72216688		 72216689
72216687		 72216681 72219865
New Holland E805   1/05-12/06 Isuzu 6WG1TC KUJ0309 KUJ0368 KUC0019
KUC0019		 KUC0017
KUC0017		 KUP0048
KUP0048		 KUB10010 KUP10150
New Holland E805   7/06-12/09 Isuzu 6WG1TC KUJ0309 KUJ10940   KUC10010
KUC10010		 KUC10020
KUC10020		 KUB10010 KUA10580
New Holland B Series Excavators
New Holland E70BSR YT05-15001 1/08-12/14 Isuzu AU-4LE2X YT10V00016F1 YT30V00039F1 YT15V00015F1 YT15V00016F1 YT32W00006F1 YT40F00004F1 YT15V00012F1
New Holland E70BSR YT06-18001 1/10-12/14 Isuzu AU-4LE2X YT10V00023F1 YT30V00047F4 YT15V00015F1 YT15V00016F1 YT32W00006F1 YT40F00004F1 YT15V00012F1
New Holland E80BMSR LF05-04001 1/08-12/14 Isuzu AU-4LE2X YT10V00016F1 YT30V00039F1 YT15V00015F1 YT15V00016F1 YT32W00006F1 YT40F00004F1 YT15V00012F1
New Holland E80BMSR LF06-04501 9/10-7/13 Isuzu AU-4LE2X YT10V00023F1 LF30V00005F4 YT15V00015F1 YT15V00016F1 YT32W00006F1 YT40F00004F1 YT15V00012F1
New Holland E135BSR YY05-12001 1/07-12/11 Mitsubishi D04FD-TAA YY10V00013F1 YY30V00063F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00015F1
New Holland E135BSRLC YH05-07001 1/07-12/11 Mitsubishi D04FD-TAA YY10V00013F1 YY30V00063F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00015F1
New Holland E135BSRLC YH06-08001 1/07-12/11 Mitsubishi D04FD-TAA YY10V00013F4 YY30V00063F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00015F1
New Holland E135B   1/08-12/14 Mitsubishi D04FR 87751800 87475091 87476717 YY15V00018F1 YY32W00004F1 87728290 87727511
New Holland E135B NALA09774 4/10-1/15 Mitsubishi D04FR YY10V00016F3 87475091 87476717 YY15V00018F1 YY32W00004F1 87728290 87727511
New Holland E150BSR YL06-01201 1/08-12/14 Mitsubishi D04FD-TAA YY10V00016F1 YY30V00063F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00006F2
New Holland E150BSR LH01-05001 1/11-12/14 Mitsubishi D04FD-TAA YY10V00016F1 YY30V00063F1 YY15V00021F1 YY15V00019F1 YY32W00004F1 YY40F00009F1 YY15V00006F2
New Holland E175B   4/07-12/11 CNH 445TA/MLF 87751365 YM30V00008F2 87693420 87571454 87693424 87601533 87357868
New Holland E175B NALA09633 4/10-1/12 CNH 445TA/MLF 87751365 YM30V00008F2 YM15V00004F3 87571454 YM32W00008F2 87601533 87357868
New Holland E195B   4/07-12/11 CNH 445TA/MLF YB10V00001F1 72206457 72211270 72211912 72203590 72260052 87357869
New Holland E195B NALA09645 4/10-4/12 CNH 445TA/MLF YB10V00005F2 YB30V00017F2 87693786 87571451 87693791 87355712 84142692
New Holland E215B N6LA05579 12/06-12/11 CNH 667TA/MEB YN10V00043F1 YN30V00116F5 YN15V00036F3 87540130 YN32W00022F2 87472588 84142692
New Holland E215B NALA09627 4/10-10/13 CNH 667TA/MEB YN10V00043F1 YN30V00116F5 YN15V00036F3 87540130 YN32W00022F2 87472588 84142692
New Holland E215B   1/07-12/10 Hino J05E-TG YN10V00036F1 YN30V00101F1 YN15V00036F1 YN15V00035F1 YN32W00019F1 YN40F00026F1 YN15V00037F1
New Holland E225BSR YB05-03001 9/07-12/14 Hino J05E-TA-KSDD YF10V00007F1 YB30V00022F1 YB15V00012F2 YB15V00011F1 YB32W00010F1 YB40F00011F1 YN15V00037F1
New Holland E225BSRLC LA05-02001 9/07-12/14 Hino J05E-TA-KSDD YF10V00007F1 YB30V00022F1 YB15V00012F2 YB15V00011F1 YB32W00010F1 YB40F00011F1 YN15V00037F1
New Holland E225BSRLC LA05-02001 1/11-10/12 Hino J05E-TA-KSDD YF10V00007F2 YB30V00022F3 YB15V00012F3 YB15V00011F1 YB32W00010F2 YB40F00011F1 YN15V00037F2
New Holland E235BSR YF05-02001 5/07-12/12 Hino J05E-TA-KSDD YF10V00007F1 YF30V00011F1 YF15V00003F1 YF15V00004F1 YF32W00001F1 YF40V00007F1 LQ15V00020F1
New Holland E235BSRLC YU05-02001 5/07-12/12 Hino J05E-TA-KSDD YF10V00007F1 YF30V00011F1 YF15V00003F1 YF15V00004F1 YF32W00001F1 YF40V00007F1 LQ15V00020F1
New Holland E235BSRLC YU06-03001 11/10-12/12 Hino J05E-TA-KSDD YF10V00007F2 YF30V00011F3 YF15V00003F1 YF15V00004F1 YF32W00001F1 YF40V00007F2 LQ15V00020F3
New Holland E245B   1/07-12/11 Iveco F4GE9684E*J600 87528088 87524899 YN15V00036F3 87540130 YN32W00022F2 87472588 LQ15V00020F3
New Holland E245B NALA09628 4/10-3/12 CNH 667TA/MEB 87528088 YN30V00116F4 YN15V00036F3 87540130 YN32W00022F2 87472588 LQ15V00020F3
New Holland E265B   9/07-12/11 CNH 667TA/EEE 87640733 LQ30V00028F2 LQ15V00025F1 87622263 87622274 87472593 LQ15V00020F3
New Holland E265B NALA09740 4/10-12/11 CNH 667TA/EEE LQ10V00019F2 LQ30V00028F2 LQ15V00025F1 87622263 87622274 87472593 LQ15V00020F3
New Holland E305B N7LA07840 11/07-12/11 CNH 667TA/EEA LQ10V00021F1 LB30V00012F2 84191023 84191794 87678996 87472707 72225043
New Holland E305B NALA09708 6/10-2/12 CNH 667TA/EEE LQ10V00021F1 LB30V00012F2 84191023 84191794 87678996 87472707 72225043
New Holland E385B   10/07-12/11 Hino EB-J08E-TM 84223606 LC30V00034F3 84191834 84191794 87568031 87472713 84223863
New Holland E385B NALA09675 6/10-10/12 Hino EB-J08E-TM 84223606 LC30V00034F3 84191834 84191794 87568031 87472713 84223863
New Holland E485B   4/08-12/11 Hino EA-P11C-UP 87696299 87700881 87699844
87699843		 87699832
87699431		 87699432
87699432		 87700311 72219865
New Holland E485B NALA09631 4/10-1/13 Hino EA-P11C-UP 87696299 87700881 87699844
87699843		 87699832
87699431		 87699432
87699432		 87700311 72219865
New Holland C Series Excavators
New Holland E75CSR YT08-30001 1/12-12/13 Isuzu AP-4LE2X YT10V00027F1 YT30V00065F1 YT15V00015F3 YT15V00016F3 YT32W00006F1 YT40F00007F1 YT15V00019F1
New Holland E85CMSR LF06-04501 3/13-12/14 Isuzu AP-4LE2X YT10V00027F1 YT30V00081F1 YT15V00015F3 YT15V00016F3 YT32W00006F1 YT40F00007F1 YT15V00019F1
New Holland E140CSR YH07-09001 12/11-12/14 Mitsubishi D04EG-TAA YY10V00013F4 YY30V00078F1 YY15V00028F1 YY15V00034F1 YY32W00004F1 YY40F00018F1 YY15V00015F1
New Holland E160CBR   1/12-12/14 Mitsubishi D04EG-TAA YY10V00013F5 YY30V00078F1 YY15V00021F1 YY15V00022F1 YY32W00004F1 YY40F00009F1 YY15V00006F1
New Holland E175C NBLA10571 1/12-12/15 FPT F4HFE413H*A001 YB10V00005F2 YM30V00012F1 YM15V00008F1 87571454 YM32W00009F1 87601533 YN15V00067F1
New Holland E175C NCLA 2/13-12/15 FPT F4GE9484E*J620 YB10V00005F2 YM30V00012F1 YM15V00008F1 87571454 YM32W00009F1 87601533 YN15V00067F1
New Holland E195C NCLA10623 2/12-12/15 FPT F4HFE413H*A001 YB10V00005F2 YM30V00012F1 YM15V00008F1 87571454 YM32W00009F1 87601533 84142001
New Holland E215C NBLA10274 10/11-12/15 FPT F4HFE613S*A002 YN10V00039F2 YN30V00129F1 YN15V00054F1 YN15V00055F1 YN32W00025F1 87472588 84142001
New Holland E215C NCLA10883 7/12-12/15 FPT F4GE9684E*J600 YN10V00039F2 YN30V00129F1 YN15V00054F1 YN15V00055F1 YN32W00025F1 87472588 84142001
New Holland E230CSR LA07-03001 1/12-12/15 Hino J05ETJ-KSDR YF10V00007F2 YB30V00025F1 YB15V00018F1 YB15V00017F1 YB32W00012F1 YB40F00011F1 YN15V00051F4
New Holland E245C NBLA10550 10/11-12/15 FPT F4HFE613S*A002 YN10V00039F3 YN30V00129F1 YN15V00054F1 YN15V00055F1 YN32W00025F1 87472588 LQ15V00031F2
New Holland E245C NCLA10889 7/11-12/15 FPT F4GE9684E*J600 YN10V00039F4 YN30V00126F1 YN15V00054F1 YN15V00055F1 YN32W00025F1 87472588 LQ15V00031F2
New Holland E260CSRLC YU07-04001 3/12-12/15 Hino J05ETJ-KSDR YF10V00007F3 YN30V00127F1 YF15V00005F1 YY15V00006F1 YF32W00005F1 YF40F00007F2 LQ15V00031F2
New Holland E265C NBLA09945 3/11-12/15 FPT F4HFE613R*A004 LQ10V00018F2 LQ30V00039F1 87622276 87622263 87622274 87472593 LQ15V00020F4
New Holland E265C NCLA10717 3/12-12/15 FPT F4HE9684C*J106 LQ10V00018F4 LQ30V00034F1 87622276 87622263 87622274 87472593 LQ15V00031F2
New Holland E305C NBLA09886 2/11-12/15 FPT F4HFE613P*A004 LQ10V00018F2 LB30V00013F1 84191023 84191794 87678996 87472707 72225043
New Holland E305C NCLA10793 4/12-12/15 FPT F4HE9684B*J104 LQ10V00018F2 LB30V00013F1 84191023 84191794 87678996 87472707 72225043
New Holland E385C NBLA10213 9/11-12/15 Hino J08E-UV-EFDC LC10V00029F2 LC30V00041F1 84191834 84191794 87568031 87472713 LC15V00023F2
New Holland E385C NCLA10849 1/12-12/15 Hino J08E-UN-EFDB LC10V00029F4 LC30V00041F1 84191834 84191794 87568031 87472713 47543437
New Holland E485C NBLA10557 12/11-12/15 Hino P11C-VC-EFDB LS10V00021F1 LS30V00017F1 LS15V00029F1
LS15V00028F1		 LS15V00027F1
LS15V00026F1		 LS32W00016F1
LS32W00016F1		 87700311 72219865
New Holland E485C NCLA 1/12-12/15 Hino P11C-UP-EFDA LS10V00021F1 LS30V00017F1 LS15V00029F1
LS15V00028F1		 LS15V00027F1
LS15V00026F1		 LS32W00016F1
LS32W00016F1		 87700311 72219865
New Holland Wheel Excavators
New Holland WE150   11/08-12/12 CNH F4GE9484E*J600 6559073 6558336 6553136 8911097 87705980 87592732 8911104
New Holland WE170   11/08-12/12 CNH F4GE9484E*J600 6559082 87751909 6553136 8911097 87705980 87592732 8911104
New Holland WE190   7/09-12/12 CNH F4GE9684E*J601 6559063 6558351 84372797 8911097   2929499
New Holland WE210   1/09-12/12 CNH F4GE9684G*J600 6559078 6558352 8926653 8911097 6551734 2929499
New Holland WE230   1/09-12/12 CNH F4GE9484G*J600 6559080 6558358 8926654 8926504   2929499
Fiat Kobelco Mini Excavators
Fiat Kobelco E9SR PA02-01831 2/03-12/04 Yanmar 2TN68-YB 72953644 72953677 PA15V00001F1     PA40F00003F1 PA15V00002F1
Fiat Kobelco E16 Evolution   4/03-12/04 Yanmar 3TNE74-ENYBC PE10V00001F1 72274560 72271587     72271600 72271598
Fiat Kobelco E18 Evolution   4/03-12/04 Yanmar 3TNE74-ENYBC PE10V00001F1 72274560 72271587     72271600 72271598
Fiat Kobelco E20SR PM06-05649 1/03-8/04 Yanmar 3TNE74-NYB 72952229 72952433 PM15V00014F1     PM40F00014F1 72952301
Fiat Kobelco E20.2SR N4TN31010 9/04-12/04 Yanmar 3TNV82A-SYB PM10V00017F1 PM30V00036F1 PM15V00020F1     72283088 72282278
Fiat Kobelco E22SR PM06-05647 1/03-8/04 Yanmar 3TNE74-NYB 72952229 72952433 PM15V00014F1     PM40F00014F1 72952301
Fiat Kobelco E22.2SR N4TN31010 9/04-12/04 Yanmar 3TNV82A-SYB PM10V00017F1 PM30V00036F1 PM15V00020F1     72283088 72282278
Fiat Kobelco E25SR PV09-22047 1/03-12/04 Yanmar 3TNE74-NYBB PM10V00013F2 72952433 72952703     PM40F00014F1 72952704
Fiat Kobelco E27.2SR N4TN31010 9/04-12/04 Yanmar 3TNV82A-SYB PM10V00017F1 PM30V00036F1 PM15V00020F1     72283088 72281630
Fiat Kobelco E30SR PW10-22027 1/03-8/04 Yanmar 3TNE82A-EYBC 72951169 72951333 PW15V00016F2     72951336 72951219
Fiat Kobelco E30.2SR N4TN31010 9/04-12/04 Yanmar 3TNV88-PYB PM10V00017F1 PX30V00041F2 PX15V00024F1     72281139 72280157
Fiat Kobelco E35SR PX11-08900 1/03-8/04 Yanmar 3TNE82A-EYBC 72951797 72951850 PX15V00018F2     72951336 72951219
Fiat Kobelco E35.2SR N4TN31010 9/04-12/04 Yanmar 3TNV88-PYB PX10V00013F1 PX30V00041F2 PX15V00024F1     72281139 72280157
Fiat Kobelco E40SR PH04-02801 2/03-8/04 Yanmar 4TNE84 PH10V00004F1 72952839 PH15V00007F1 PH15V00011F1 PH32W00004F1 72952851 72952827
Fiat Kobelco E40.2SR PH05-03501 9/04-12/04 Yanmar 3TNV88-PYB 72283618 72283627 PY15V00012F1     72284219 72284190
Fiat Kobelco E40.2SR PH05-03547 9/04-12/04 Yanmar 3TNV88-PYB 72285151 72283627 PY15V00012F1     72284219 72284190
Fiat Kobelco E40.2SR PH05-03682 9/04-12/04 Yanmar 3TNV88-PYB 72285151 72285491 PY15V00012F1     72284219 72284190
Fiat Kobelco E40.2SR PH05-03878 9/04-12/04 Yanmar 3TNV88-PYB 72285151 87341195 PY15V00012F1     72284219 72284190
Fiat Kobelco E45SR PJ03-01001 2/03-12/05 Yanmar 4TNE88 PY10V00009F1 72952905 PY15V00007F1 PY15V00010F1 PY32W00004F1 72952851 72952904
Fiat Kobelco E50.2SR   9/04-12/04 Yanmar 4TNV88-XYB 72283618 87341195 PY30V00032F2     72284216 72284190
Fiat Kobelco Excavators
Fiat Kobelco E70SR YT02-04001 1/03-12/04 Isuzu CC-4JG1-PYA YT10V00002F2 72950219   72950197 YT32W00002F2 2425U261F1 72950198
Fiat Kobelco E70SR YT05-05140 1/03-12/04 Isuzu CC-4JG1-PYA YT10V00002F2 72150003   72950197 YT32W00002F2 2425U261F1 72950198
Fiat Kobelco E80   4/03-12/04 Isuzu CC-4JG1-PYA YT10V00002F2 72962365   72950197 YT32W00002F2 2425U261F1 YT15V00008F1
Fiat Kobelco E115SR YV02-01953 1/03-12/04 Isuzu BB-4BG1T 72953800 72958180 72953456 72958745 YX32W00002F2 24100N7529F1 YX15V00003F4
Fiat Kobelco E115SR YV02-02381 1/03-12/04 Isuzu BB-4BG1T 72150078 72958180 72150146 72150390 YX32W00002F2 72150425 YX15V00003F4
Fiat Kobelco E135 Evolution   1/04-12/04- Iveco F4BE0454B*D601 72214020 72206455 72214150 72214467 72214466 72206928 72214452
Fiat Kobelco E135SR YY02-03885 1/03-12/04 Isuzu BB-4BG1T 72953800 72953813 72959953 72953780 YX32W00002F2 24100N7529F1 72150092
Fiat Kobelco E135SRLC YH02-01702 1/03-12/04 Isuzu BB-4BG1T 72953800 72953813 72959953 72953780 YX32W00002F2 24100N7529F1 72150092
Fiat Kobelco E135SR YY02-04575 1/03-12/04 Isuzu BB-4BG1T 72150078 72953813 72150079 72214467 YX32W00002F2 24100N7529F1 72150092
Fiat Kobelco E135SRLC YH02-02075 1/03-12/04 Isuzu BB-4BG1T 72150078 72953813 72150079 72214467 YX32W00002F2 24100N7529F1 72150092
Fiat Kobelco E165 Evolution   1/03-12/04 Iveco F4BE0484E*D607 72204983 72205217 72204981 72203588   72200589 72208974
Fiat Kobelco E195 Evolution   9/03-12/04 Iveco F4BE0484D*D608 YB10V00001F1 72211272 72211270 72211912 72203590 72260052 72206512
Fiat Kobelco E200SR LA04-01210 1/03-12/04 Isuzu AA-4BG1TC 72953946 72953976   72953965 YB32W00001F1 YB40F00001F1 YN15V00011F4
Fiat Kobelco E200SR LA04-01239 1/03-12/04 Isuzu AA-4BG1TC YB10V00001F1 72953976   72953965 YB32W00001F1 YB40F00001F1 YN15V00011F4
Fiat Kobelco E215 Evolution   1/03-12/04 Iveco F4BE0684B*D402 72204145 72203576 72203589 72203588   72203516 72206512
Fiat Kobelco E235 Evolution   1/03-12/04 Iveco F4BE0684B*D402 72204145 72203576 72203589 72203588   72203516 72210201
Fiat Kobelco E235SR   3/03-12/04 Mitsuvishi 6D34-TLU2D 72959679 72959705   72959688 72959608 72959706 LQ15V00007F2
Fiat Kobelco E235SR   3/03-12/04 Mitsuvishi 6D34-TLU2D 72150711 72959705   72150166 72959608 72959706 72150719
Fiat Kobelco EX255   1/02-1/04 Isuzu 6BG1TRA-05 72105811 71466728 71465047 71470188   71401651 71464513
Fiat Kobelco E265 Evolution   2/04-12/04 Iveco F4AE0684L 72211797 72213195 72212978 72212979 72212980 72212986 72210201
Fiat Kobelco EX285   1/02-2/04 Isuzu 6BG1TRA-06 72105809 71467113 71466938 71471272   71401651 71467072
Fiat Kobelco E305 Evolution   3/04-12/04 Iveco F4AE0684K*D101 72211800 72215986 72212982 72212983 72212984 72212986 72225043
Fiat Kobelco E385 Evolution   11/03-12/04 Isuzu 6HK1XQY 72208819 72210720 72209782 72208949 72208950 72208804 72214435
Fiat Kobelco EX455   1/02-6/04 Isuzu 6WG1TQA-01 72106695 71449100 71432281
71432280		 71452752
71452752		 71463034
71433899		 71403020 71472665
Fiat Kobelco E485 Evolution   7/04-12/04 Isuzu 6SD1XQY 72216529 72216543 72216533
72216532		 72216690
72216688		 72216689
72216687		 72216681 72219865
Fiat Kobelco Wheel Excavators
Fiat Kobelco EX95W 087WT0051 7/02-2/04 Perkins 1004-42 72108892 71484009 71484710 71476286   151910073 71491100
Fiat Kobelco EX95W 087WT0063 7/02-2/04 Perkins 1004-42 72108892 71492384 71491029 71476286   151910073 71491100
Fiat Kobelco E95W Evolution 089WT00337 3/04-12/04 Iveco F4BE0454B*D602 71484011 72117139 72109018 72108894 72109019 151910073 72117104
Fiat Kobelco EX125W 117WT0051 7/02-3/04 Perkins 1004-40T 71489437 71489438 71490118 71476394   151910073 71489691
Fiat Kobelco EX125W 117WT0080 7/02-3/04 Perkins 1004-40T 71489437 71492385 71491030 71476394   151910073 71489691
Fiat Kobelco E125W Evolution 119WT00387 4/04-12/04 Iveco F4BE0484E*D605 72108893 72109252 72112221 72108894 72113006 151910073 72117119
Fiat Kobelco E145W Evolution   1/05-12/04 Iveco F4BE0484E*D601 72104853 72104855 72105401 72104860 72111445 72103600 71437621
Fiat Kobelco E175W Evolution   1/03-12/04 Iveco F4BE0684E*D401 72104854 72104856 72107631 72104860 72109022 151910082 72104858
Fiat Kobelco E195W Evolution   3/04-12/04         8911096 2814450
Запчасти для спецтехники
( 259 )
Роман Петров Петрович Главный гидравлист Украины
Роман Петров Петрович Главный гидравлист Украины
Председатель сообщества гидравлистов Украины
Комментарии
Пока нет комментариев
Написать комментарий
Имя*
Email
Введите комментарий*
24 + ? = 27
Введите капчу*
